Appliance door en
If the door hinge has been damaged, call the after-
sales service.
Carefully move the appliance door back and forth in
the direction of both arrows until you hear a quiet
click. You can still only move the appliance door
slightly.
The appliance door is in the lock position.
6.
WARNING‒Risk of injury!
The appliance door has a weight of 7–10 kg and may
fall if it is not handled carefully.
Handle the appliance door carefully.
Take hold of the appliance door with both hands, one
on the left and one on the right, and at the same time
slightly rotate the door handle upwards until you
are able to pull up the appliance door and remove it
.
7.
Set the appliance door down on a flat, soft, clean sur-
face.
20.2 Attaching the appliance door
Tip: Ensure that the appliance door is not wedged at
an angle and that it is properly fitted in place.
1.
Attach the appliance door via the left- and right-hand
guide rollers simultaneously .
2.
Rotate the door handle upwards slightly .
The appliance door will slide the short distance re-
maining to the bottom .
3.
Use a coin to release both locks on the appliance
door. Insert the coin in the gap in the lock and ro-
tate as far as it will go .
Turn the lock on the left-hand side in an anti-clock-
wise direction.
Turn the lock on the right-hand side in a clockwise
direction.
4.
Open the appliance door slightly until you hear a
quiet click, and then close the appliance door.
5.
WARNING‒Risk of injury!
If the door locks are unsecured, the appliance door
may become detached.
After attaching the appliance door, close the left-
and right-hand door locks.
27
