ENG-14

ENG-15

Troubleshooting

Stylus pen does not work.

• IstheUSBcableconnectedbetweenthecomputer(typeAUSBport)andthecameraunit(typeB

USB port)?

• Havethedriverandthecalibrationsoftwarebeeninstalledonyourcomputer?

• Areyouusingthestyluspeninoneofthefollowingenvironment?

- If direct sunlight strikes the screen surface and/or camera unit, change the installation place where

it is not exposed to direct sunlight.

- If light of a halogen and/or a filament lamp strikes the screen surface and/or camera unit, change

the installing direction of the screen and/or camera unit, or block off lamp light.

- Donotuseascreenwhosematerialofframereectslight.

 InuenceofexternallightisdescribedatthetroubleshootingintheNP04Wisoftwareguide.Refer

to the software guide on the support page for our projectors uploaded in our web site and set them

upinanappropriateplacewheredoesnotgetinuenceoflight.

• Isthecameraunitsettothecorrectposition?

• Doesthestyluspenhavepropercharge?

If pressing the pen tip will not turn LED to red, charge the stylus pen.

• Isthescreensizeandusagetemperaturewithinappropriaterange?

Use a screen within the effective range.

Usethestyluspenwithinatemperaturerangeof5°to40°C(41°to104°F).

• Isthelensofthecameraunitsoiled?

 Ifthelensissoiled,wipeitwithasoft,dry,non-uffycloth.

Lines traced with the stylus pen do not match screen.

• Hasthesensorbeenproperlycalibrated?

• Ifperformingthecalibrationautomaticallywillnotresolvetheproblem,trytoperformthecalibration

manually.

Specifications

Camera unit

• Inputterminal:USBTypeB×1

• Powerconsumption:120mA/5V,600mW

• Weight:70g/2.5oz

• Externaldimensions:135(W)x32(H)x36(D)mm/5.3"(W)x1.3"(H)x1.4"(D)(notincludingprotru-

sions)

• Effectiverange:60"to100"

• Operatingtemperatureandhumidity:5°to40°C(41°to104°F)/20%to80%(non-condensing)

• Storagetemperatureandhumidity:−10°to50°C(14°to122°F)/20%to80%(non-condensing)

Stylus pen

• Weight:25g/0.9oz

• Powersupply:Chargingtype(supercapacitor)

• Chargingtime:3minutes

• Estimatednumberofchargingthebattery:100,000

• Operatingtime:about2hours

• Operatingtemperatureandhumidity:5°to40°C(41°to104°F)/20%to80%(non-condensing)

• Storagetemperatureandhumidity:−10°to50°C(14°to122°F)/20%to80%(non-condensing)
