English - 34
Removing a pixel card (in case of rear installation)
In the case of rear installation, remove the pixel cards by pushing them from the rear of the LED
modules.
CAUTION
• To replace the upper pixel cards, do it after removing the lower pixel cards.
• The pixel cards contain powerful magnets. If magnetic cards come close to the pixel cards, the data contained
within may be damaged. Therefore, do not carry any magnetic card when installing the pixel cards.
• When installing or removing the pixel cards, pay attention not to damage them against the pixel cards
already installed or other objects. Otherwise, the video may not be displayed properly.
• Check that the safety wire is connected before removing the pixel card.
CAUTION
If a pixel card is pushed at an angle, the part where the pixel contacts the cabinet may be damaged.
Push the pixel card straight.
Correct removal If pushed at an angle
To remove a pixel card, push gradually the locations (1) and (2) on the pixel card as shown in the
gure below.
(1)
(2)
