2. Wiring
(1) Maximum number of signal connections
The maximum number of connections per LAN cable is shown below.
Product name Maximum number of connections
LED-Q028i2 20 modules
LED-Q039i2 39 modules
LED-Q028e2 20 modules
LED-Q039e2 39 modules
LED-Q048e2 60 modules
LED-Q059e2 92 modules
LED-Q078e2 158 modules
CAUTION
The maximum number of connections may differ depending on the connected LED controller. Therefore,
check the specications of the LED controller you are using.
Ask a technician or your retailer for more details.
(2) Maximum number of power connections
CAUTION
Exceeding the maximum capacity may generate smoke or cause a re.
Check the voltage used and do not exceed the connection limits shown below.
LED-Q028i2 LED-Q039i2 LED-Q028e2 LED-Q039e2
100 - 120 V AC 8 modules 8 modules 8 modules 8 modules
200 - 240 V AC 12 modules *
1
12 modules *
1
12 modules *
1
12 modules *
1
LED-Q048e2 LED-Q059e2 LED-Q078e2
100 - 120 V AC 8 modules 8 modules 8 modules
200 - 240 V AC 12 modules *
1
12 modules *
1
12 modules *
1
*1: The values shown are when using 16 A D-type circuit breakers.
