English - 9
No. Parts Specications
Quantity
4 x 4
frame set
5 x 5
frame set
6 x 6
frame set
8 x 8
frame set
Screw for overframe (M4×4) Hexagon socket head
screw
8
(3+5*
1
)
9
(4+5*
1
)
9
(4+5*
1
)
9
(4+5*
1
)
Screw for overframe (M4×8) Hexagon socket head
screw
12
(7+5*
1
)
13
(8+5*
1
)
13
(8+5*
1
)
17
(12+5*
1
)
Screw for cabinet (to Power
bar)
(M8×16)
Hexagon socket head
screw
13
(8+5
*
1
)
15
(10+5*
1
)
17
(12+5*
1
)
21
(16+5*
1
)
Adjustment plate 10 12 14 18
Screw for Adjustment plates Hexagon socket head
screw (M4 x 16)
45
(40+5*
1
)
53
(48+5*
1
)
61
(56+5*
1
)
77
(72+5*
1
)
Screw for connecting
cabinets
(M8×25)
53
(48+5*
1
)
85
(80+5*
1
)
125
(120+5*
1
)
229
(224+5*
1
)
LAN cable for the LED modules
120 mm 12 20 18 48
Alignment bar 2 2 2 2
USB ash memory 1 1 1 1
Safety Manual 1 1 1 1
Precautions for installation
sheet
1 1 1 1
LED controller*
2
Novastar MCTRL660
PRO
1 1 - -
Novastar MCTRL4K - - 2 1
LAN cable between LED
controller and module*
2
20000 mm 4 5 18 8
24000 mm - - - 8
Power cord for the LED
controller*
2
1 1 2 1
Power cord*
3
*
3
*
3
*
3
*
3
*1: Spare parts
*2: Kit model only (except for LED-FC012i-11N, LED-FC015i-13N, LED-FC009i-16N, LED-FC012i-22N)
*3: Can be ordered by optional
Four different wall-mount frames can be used depending on the system size. Ask your retailer for more details.
For other congurations, the number of contents will vary. Please contact your retailer for more information.
