English - 93
4.3 Conguring the settings with one LED controller connected to the PC using a USB cable
Connect the LED controllers and the LED modules with LAN cables.
Terminate the Backup system connection at the RJ-45 connector located top left on the last module in the
daisy chain connection.
LED controllers
LED modules
* For the MCTRL 4K LED controller, the way to make connections is similar to this example.
LED-ELED-FE/FC
Start the control software NovaLCT and log in with the administrator privileges.
Display the login screen as follows: User(U) -> Advanced Synchronous System UserLogin(A). Enter the
password (“admin”) to log in with the administrator privileges.
Click “Screen Conguration”.
