12. Wiring
(1) Maximum number of signal connections
The maximum number of connections per LAN cable is shown below.
Product name Maximum number of
connections
Product name Maximum number of
connections
LED-FA009i2 2 modules LED-FE009i2 2 modules
LED-FA012i2 5 modules LED-FE012i2 5 modules
LED-FA012i2-SB 5 modules LED-FE015i2 7 modules
LED-FA015i2 7 modules LED-FE019i2 10 modules
LED-FA015i2-SB 7 modules LED-FE025i2 20 modules
LED-FA019i2 10 modules LED-FE031i2 30 modules
LED-FA025i2 20 modules LED-FE038i2 40 modules
LED-FA031i2 30 modules LED-FE012i2-E 5 modules
LED-FA038i2 40 modules LED-FE015i2-E 7 modules
LED-FE019i2-E 10 modules
CAUTION
The maximum number of connections may differ depending on the connected LED controller. Therefore,
check the specications of the LED controller you are using.
Ask a technician or your retailer for more details.
(2) Maximum number of power connections
CAUTION
Exceeding the maximum capacity may generate smoke or cause a re.
Check the voltage used and do not exceed the connection limits shown below.
Except Taiwan, Korea and India:
Product name 100 - 120 V AC 200 - 240 V AC
LED-FA009i2 10 modules 18 modules
LED-FA012i2 13 modules 25 modules
LED-FA012i2-SB 13 modules 25 modules
LED-FA015i2 13 modules 25 modules
LED-FA015i2-SB 13 modules 25 modules
LED-FA019i2 13 modules 25 modules
LED-FA025i2 13 modules 25 modules
LED-FA031i2 13 modules 25 modules
LED-FA038i2 13 modules 25 modules
Product name 100 - 120 V AC 200 - 240 V AC
LED-FE009i2 10 modules 18 modules
LED-FE012i2 13 modules 25 modules
LED-FE015i2 13 modules 25 modules
LED-FE019i2 13 modules 25 modules
LED-FE025i2 13 modules 25 modules
LED-FE031i2 13 modules 25 modules
LED-FE038i2 13 modules 25 modules
LED-FE012i2-E 13 modules 25 modules
LED-FE015i2-E 13 modules 25 modules
LED-FE019i2-E 13 modules 25 modules
