Parameters
Specifications
Description
The vacuum mop voice prompts "Dirty water tank full.
Please empty it" and pauses
The vacuum mop voice prompts "Clean water tank short of
water. Please refill it" and pauses
The vacuum voice prompts "Pipe clogged. Please manually
clean the pipe and the roller brush" during cleaning or
self-cleaning
The vacuum voice prompts "Uneven roller brush iron
drying. Please check whether it is installed properly"
Possible Causes and Solutions
Rinse the dirty water tank and the filter
Fill water into the clean water tank or check whether the
clean water tank is installed properly
As a consistently high dirt level is detected, there may
be residual dirt in the pipe. You are recommended to
clean the pipe with the cleaning brush
Check whether the roller brush is properly installed
There is residual water inside the vacuum after unboxing
Each vacuum will receive strict functional tests before
delivery, and there may be a small amount of water remaining,
which will not aect the vacuum
The floors get dirtier when the vacuum is working
The vacuum loses suction power after a period of time
The roller brush suddenly stops rotating when the
vacuum is working
The vacuum keeps warning that "Dirty water tank full.
Please clean up the dirty water tank" when the dirty water
tank is not full and the MAX water level is not yet reached
Voice reminder: “Base scissors abnormal. Please check
and clean.”
There is too much dirt on the roller brush, so it is recommend-
ed that you put the vacuum back on the base for self-cleaning
There may be stubborn stains and waste residue aecting
the normal performance of the washer. It is recommended
that you remove and clean the roller brush cover, roller brush,
pipe, and filter.
The roller brush may be entangled with or the space
between the roller brush and the cover is clogged with
foreign objects, causing the roller brush to stop rotating.
You can turn o the vacuum mop and remove the roller
brush cover and the roller brush to clear the foreign
objects. It is recommended to put away the data cables,
plastic bags, and shoelaces on the floor before cleaning,
to prevent them from entangling the roller brush and
stopping its rotation, which may damage both the
vacuum mop and items on the floor
The solid waste box in the dirty water tank may be full of
waste, or the vacuum mop may suck in easy foaming
liquids (laundry detergent, detergent, urine, etc.). In this
case, please clean the dirty water tank and the roller
brush immediately, put them back, and then try again To
prevent leakage due to inclining during cleaning, the
vacuum mop would prompt a full dirty water tank when
dirty water reaches any of the three lines below the MAX
line. You should timely clean the dirty water tank
There may be foreign objects causing the scissors to
malfunction. Please check for blockages around the
base of the scissors and the outlet; if present, clean
them manually (ensure safety to avoid injury)
Wet Dry Vacuum
Self-cleaning base
Adapter
Baery: 4000mAh
Clean water tank volume: 790ml
Dirty water tank volume: 720ml
Rated Power: 160W
Rated Input: 27V 1.0A
Rated Output: 27V 1.0A
Dimensions: 247*273*1172 mm
Weight: ~4.35kg (empty water tank)
Rated Input: 27V 1.0A
Rated Voltage: 21.6V (lithium ion baery
Dimensions: 340*296*235 mm
Weight: ~1.13kg
Rated Input: 100-240V~, 50/60Hz, 0.8A
Rated Output: 27V 1.0A
06
