To switch Single Screen video signal source to USB 1 port press the button
To switch Single Screen video signal source to USB 2 port press the button
To switch Single Screen video signal source to HDMI 3 port press the button
By pressing the button to enter PBP mode, press the buttons to select two video
sources you want to output as shown in the following example:
© MuxLab Inc. 2025 8 94-001061-A/SE-001061-A
USB/HDMI Video Selector and Mixer
⚫
⚫
⚫
8.2 Dual Screen Display
8.2.1 PBP Mode
To switch PBP signal source to USB 1 and USB 2 press the buttons and
To switch PBP signal source to USB 1 and HDMI 3 press the buttons and
To switch PBP signal source to USB 2 and HDMI 3 press the buttons and
During the PBP on display, press the PBP control button again to swap the left and the right
video source display from each other.
⚫
⚫
⚫
⚫
