© MuxLab Inc. 2025 5 94-001061-A/SE-001061-A
5. Specifications
USB/HDMI Video Selector and Mixer
HDMI 1.4 (1080p), HDMI2.0 (4K/60) and USB (UAC/UVC)
Cameras, PCs/Laptops, projectors/monitors/TVs
500882 USB/HDMI Video Selector and Mixer (UPC: 627699008829)Order Information
Enviroment
Transparent to the user
Specification
HDMI Devices
Transmission
Frequency
Connectors
Locally via front panel push buttons, RS232 and Ethernet
Management
2CH Analog Audio
Audio extraction
Up to 594 MHz
Video Signal HDMI 1.4/2.0 protocol and HDCP 1.4 & 2.2
Two (2) HDMI connectors for video (one HDMI 1.4 inputs and one HDMI 2.0 outputs)
One (1) USB 2.0 input for UAC/UVC Stream
One (1) USB 3.0 input for UAC/UVC Stream
One (1) USB-C 3.0 output for UAC/UVC Stream
Two (2) 3.5mm jack for Analog Stereo audio input and output
One (1) 4-POS terminal block for RS232 control
One (1) RJ45 PoE Ethernet port for IP and Web control
Power Supply
Enclosure
Power Consumption
Temperature
12VDC,1.5A
12W (max)
Operating: 0° to 40°C Storage: -20° to 60°C
Humidity: up to 90% non-condensing
Metal enclosure
Unit Dimensions
Shipping Weight
Compliance
Warranty
7.48” x 3.54” x 0.87” (190mm x 90mm x 22mm)
1.1 lbs (0.5 Kg)
Regulatory: FCC, CE, RoHS
2 years
