© MuxLab Inc. 2025 17 94-001061-A/SE-001061-A
USB/HDMI Video Selector and Mixer
2. In the Microphone drop-down option, you can test the following four options. After selecting
the corresponding one, click the button "Detect microphone" to test whether it is available and
can input sound.
As above device interface diagram showed:
>> USB 1 corresponds to the audio input of
⑨
>> USB 2 corresponds to the audio input of
⑩
>> HDMI In corresponds to the audio input of
⑪
>> Line In corresponds to the audio input of
⑮
Volume Setting > Speaker
⚫
As below example shown, HDMI OUT is checked by default , so the speaker output is currently
HDMI OUT port. The volume bar below can adjust the volume of this HDMI OUT speaker output port.
The volume bar below Master can adjust the speaker output volume of the ticked one, which has a
multiplication effect. For example, in the current example of the HDMI OUT port, when you click the
"Mute" button, a red background frame will appear , indicates that the function is enabled.
