5. Specifications
© MuxLab Inc. 2023 5 94-001012-A/SE-001012-A
KVM HDMI over IP PoE Extender Deluxe, 4K30
Enviroment
HDMI 2.0a
HDCP 1.4, HDCP 2.2
297MHz
Up to 4K/30Hz (4:4:4) or 4K/60Hz (4:2:0)
JPEG 2000
Typical one (1) Frame: 16ms for 60Hz and 33ms for 30Hz
1000BaseT with PoE
Technical
HDCP Compliance
Bandwidth (HDMI)
Video Resolution
Maximum Distance
Latency
Network Requirement
HDR10HDR Color
Cat5e/6: 330ft (100m)
Compresion
Bandwidth
Up to 500Mbps
Connection
Transmitter
1 x HDMI IN [Type A, 19-pin female]
1 x Audio Input [5pin-3.81mm Phoenix jack]
1 x HDMI Loopout [Type A, 19-pin female]
1 x Ethernet LAN port [RJ45, 8-pin connector]
1 x IR Sensor [3.5mm Stereo Mini-jack]
1 x IR Emitter [3.5mm Stereo Mini-jack]
1 x RS-232 [3pin-3.81mm Phoenix jack]
1 x USB HOST [USB Type C]
Input:
Outputs:
Controls:
Receiver
Inputs:
Outputs:
Controls:
1 x HDMI IN [Type A, 19-pin female]
1 x Ethernet LAN port [RJ45, 8-pin female]
1 x HDMI OUT [Type A, 19-pin female]
1 x Audio Output [5pin-3.81mm Phoenix jack]
1 x IR Sensor [3.5mm Stereo Mini-jack]
1 x IR Emitter [3.5mm Stereo Mini-jack]
1 x RS-232 [3pin-3.81mm Phoenix jack]
4 x USB DEVICES [USB Type A]
Mechanical
Generic Specification
Housing Metal Enclosure
Color
Black
Dimensions (WxDxH)
Transmitter/Receiver: 163mm x 107mm x 23mm
Weight
Transmitter: 485.3g, Receiver: 494.4g
Power Consumption Transmitter: 5 Watt Receiver: 7 Watt
PoE Standard IEEE 802.3af
Operating Temperature
32 - 104°F / 0 - 40°C
Storage Temperature -4 - 140°F / -20 - 60°C
Relative Humidity 20~90% RH (non-condensing)
Compliance
Warranty
Order Information
Regulatory: FCC, CE, RoHS
3 years
500850-TX KVM HDMI over IP PoE Transmitter Deluxe, 4K/30 (UPC:627699908501)
RS-232 Up to 115k Baud
IR
Bi-Directional
500850-RX KVM HDMI over IP PoE Receiver Deluxe, 4K/30 (UPC:627699808504)
