Specification
Environment
Transmission
Devices
HDMI 2.0
Transparent to the user
Technical
597MHz
Bandwidth (HDMI)
Signals
Operating: 0° to 40°C Storage: -20° to 85°C
Humidity: Up to 95% non-condensing
(110mm x 55mm x 105mm)
Temperature
HDMI 2.0 protocol, HDCP 1.4, HDCP 2.2
Dimensions (W, D, H)
PoE Standard
This device supports PoE (PD), an external power supply is not included. It is
intended to be powered via a PoE (PSE) Ethernet Switch. If required, an optional
power supply may be purchased separately.
Power Consumption
IEEE 802.3af
Computers and servers with HDMI monitor ports.
HDR10 & Dolby Vision
HDR Color
Maximum Distance
Based on a maximum
length of 6.6ft (2m) of
HDMI cable per end.
Cat5e/6: 330ft (100m) from Ethernet Switch. Unlimited over the Internet
Note: When installed in an electrically noisy environment, an STP cable must be
used. Also, cross-connection reduces the effective distance depending on the
grade of twisted cable used.
500800-TX-WP-WH KVM HDMI over IP PoE Transmitter Wall-Plate, 4K/60 (UPC:
627699928004)
Order Information
Connectors
One (1) HDMI IN connector for AV input.
One (1) RJ45S for Cat 5e/6 unshielded or shielded twisted pair.
One (1) 3.5mm jacks for audio-in
One (1) 3.5mm jack for directional Infrared port.
One (1) USB Type B Connector for Host device
One (1) 2.1mm power connector
Power Source
6 Watt
Regulatory: FCC, CE, RoHS Flammability: 94V0Compliance
Latency Typical one (1) Frame (16ms), maximum 2 frames (33ms)
Compression JPEG 2000
Bandwidth
Up to 850 Mbps
Network Requirement
1000BaseT
RJ45 Pin Configuration
Reverse Polarity Sensitive.
Use EIA/TIA 568A or 586B
straight-through wiring.
RJ45 Link
Pin 1 (R) Pin 2 (T)
Pin 3 (R) Pin 6 (T)
Pin 4 (R) Pin 5 (T)
Pin 7 (R) Pin 8 (T)
Cable
One (1) Cat 5e/6 or better twisted pair cables required
Weight
0.63lbs (1.38kg)
Warranty
2 years
