© MuxLab Inc. 2024 6 94-001020-B/SE-001020-B
IP Camera
Video Compression
Video Stream
Main Stream Resolution
Sub Stream Resolution
Bit Rate Type
frame rate
Audio Compression
Supported protocols
H.264
First and second streaming
1920x1080, 1280x720, 1024x576, 960x540, 640x480, 640x360
1280x720, 1024x576, 720x576, 720x480, 720x408, 640x360, 480x270,
320x240, 320x180
Variable bit rate，Fixed bit rate
1fps ~ 60fps
AAC
96Kbps, 128Kbps, 256Kbps
TCP/IP, HTTP, RTSP, RTMP, Onvif, DHCP, Multicast, SRT, GB/T28281
Video Bit Rate
32Kbps ~ 102400Kbps
Audio Bit Rate
Input/Output Interface
12VDC，PoE（802.3af）
Order Information 500790-V2 USB/IP PTZ Camera 30x Zoom, PoE (UPC: 627699017906)
1 x RJ45:10M/100M/1000M Adaptive Ethernet, supported PoE
HD Output
Network Interface
1 x 3G-SDI: BNC type, 800mVp-p, 75Ω, Comply with SMPTE 424M standard
Audio interface
1 x Line In, 3.5mm Audio Interface
Generic Specification
1 x RS232 Out: 8pin Min DIN, Max Distance: 30m, VISCA network use only
1 x RS485: 2-POS Terminal Block, Max Distance: 1200m, VISCA/Pelco-D/Pelco-P
Power Jack
JEITA Type（Input 12VDC）
Input Voltage
Input Current
1000mA
Operating Temperature 0°C ~ 40°C
Storage Temperature -10°C ~ 50°C
Power Consumption
12W
Size
146mm x 169mm x 168mm
Net Weight
1.5Kg
Warranty
2 years
USB 1-ch, USB 3.0: Type-A
1 x HDMI: V1.3
1 x Line Out, 3.5mm Audio Interface
Communication Interface
1 x RS232 In: 8pin Min DIN, Max Distance: 30m, VISCA/Pelco-D/Pelco-P
USB/IP PTZ Camera 30x Zoom, PoE
