KVM HDMI over IP PoE Extender, UHD-4K - 500772
© MuxLab Inc. 2021 94-000845-C / SE-000845-C
Page 5
2 Direct Switching Method
This method of switching from one workstation to another supports up to 16 workstations. It supports a
quick and simple method of switching to different workstations. If more than 16 workstations is
required, then the On Screen Display (OSD) Switching Method must be used.
Each Transmitter must have a unique Dip Switch setting (ranging from 0 to 15) which will automatically
correspond to the workstation ID. The Dip Switch represents a binary count as follows:
ID 0
ID1
ID 2
ID 3
ID 4
ID 5
ID 6
ID 7
ID 8
ID 9
ID 10
ID 11
ID 12
ID 13
ID 14
ID 15
0000
0001
0010
0011
0100
0101
0110
0111
1000
1001
1010
1011
1100
1101
1110
1111
To quickly switch from one workstation to another, say to switch from workstation ID 1 to workstation
ID 4, press and hold the “CTRL” key and while doing so quickly press “4” three times.
This will automatically switch the client operator to the workstation with ID 4.
Note that the hotkey keyboard mapping for ID 0 to ID 15 is as follows:
ID 0
ID1
ID 2
ID 3
ID 4
ID 5
ID 6
ID 7
ID 8
ID 9
ID 10
ID 11
ID 12
ID 13
ID 14
ID 15
CTRL
+
0
CTRL
+
1
CTRL
+
2
CTRL
+
3
CTRL
+
4
CTRL
+
5
CTRL
+
6
CTRL
+
7
CTRL
+
8
CTRL
+
9
CTRL
+
Q
CTRL
+
W
CTRL
+
E
CTRL
+
R
CTRL
+
T
CTRL
+
Y
