KVM HDMI over IP PoE Extender, UHD-4K - 500772
© MuxLab Inc. 2021 94-000845-C / SE-000845-C
Page 16
5 Specifications
Environment
HDMI 2.0b
Devices
Computers and servers with HDMI monitor ports.
Transmission
Transparent to the user
Bandwidth
300MHz
Signals
HDMI 2.0 b protocol, HDCP 2.2
Connectors
Note: Cables not included.
One (1) HDMI receptacle.
One (1) RJ45S for Cat 5e/6 unshielded or shielded twisted pair.
Two (2) 3.5mm jacks for audio insert (on TX)/audio extract (on RX).
One (1) 2.1mm locking barrel jack for power
One (1) or Four (4) USB Connector(s) for Host (on TX)/Client (on RX)
Four (4) DIP Switches for device ID addressing.
Maximum Distance
Based on a maximum length
of 6.6ft (2m) of HDMI cable
per end.
Cat5e/6: 330ft (100m) up to 4K @ 30Hz (4:4:4) and 4K @ 60Hz (4:2:0)
Note: When installed in an electrically noisy environment, an STP cable must be used. Also, cross-connection
reduces the effective distance depending on the grade of twisted cable used.
Latency
Typical one (1) Frame (16ms), maximum 2 frames (33ms)
Compression
JPEG 2000
Bandwidth
Up to 500Mbps
Network Requirement
1000BaseT with PoE
RJ45 Pin Configuration
Reverse Polarity Sensitive. Use
EIA/TIA 568A or 586B straight-
through wiring.
RJ45 Link
Pin 1 (R) Pin 2 (T)
Pin 3 (R) Pin 6 (T)
Pin 4 (R) Pin 5 (T)
Pin 7 (R) Pin 8 (T)
Cable
One (1) Cat 5e/6 or better twisted pair cables required
Power Source
This device supports PoE (PD), an external power supply is not included. It is intended to be powered via a PoE
(PSE) Ethernet Switch. If required, an optional power supply (500993) may be purchased separately.
PoE Standard
IEEE 802.3af
Power Consumption
Transmitter: 6Watt Receiver: 6Watt
Temperature
Operating: 0° to 40°C Storage: -20° to 85°C
