5. Specifications
© MuxLab Inc. 2023 5 94-001010-A/SE-001010-A
HDMI 2.0 KVM HDBT Extender Kit, 100m
HDMI Compliance
HDMI 2.0b
HDCP 2.2
18Gbps
Up to 4K/60Hz
HDR, HDR10, HDR10+, Dolby Vision, HLG
8/10/12-bit
12Vp-p
Technical
HDCP Compliance
Video Bandwidth
Video Resolution
Color Space
Color Depth
IR Level
HDBT Standard Mode: 4K60/100m; 1080P/100m (CAT6A/7 cable)
Transmission Distance
RGB, YCbCr 4:4:4, YCbCr 4:2:2, YCbCr 4:2:0
HDR
Audio Formats
LPCM, Dolby Digital/Plus/EX, Dolby True HD, DTS, DTS-EX, DTS-96/24,
DTS High Res, DTS-HD Master Audio, DSD
Connection
Transmitter
1 x HDMI Input [Type A, 19-pin female]
1 x HDBaseT Output [RJ45 connector]
1 x L/R Output [3.5mm Stereo Mini-jack]
1 x IR Input [3.5mm Stereo Mini-jack]
1 x IR Output [3.5mm Stereo Mini-jack]
1 x RS-232 [3pin-3.81mm Phoenix jack]
1 x SERVICE [Micro USB, 5-pin female]
1 x USB HOST [USB Type B]
2 x USB DEVICES [USB Type A]
Input:
Outputs:
Controls
:
Receiver
Inputs:
Outputs:
Controls:
1 x HDBaseT Input [RJ45, 8-pin female]
1 x HDMI Output [Type A, 19-pin female]
1 x L/R Output [3.5mm Stereo Mini-jack]
1 x IR Input [3.5mm Stereo Mini-jack]
1 x IR Output [3.5mm Stereo Mini-jack]
1 x RS-232 [3pin-3.81mm Phoenix jack]
1 x SERVICE [Micro USB, 5-pin female]
2 x USB DEVICES [USB Type A]
Mechanical
Generic Specification
Housing Metal Enclosure
Color
Black
Dimensions (WxDxH)
Transmitter/Receiver: 144mm x 78mm x 23mm
Weight
Transmitter: 323g, Receiver: 319g
Power Supply
Input: AC 100 - 240V 50/60Hz
Power Consumption 14.28W (POC)
Operating Temperature
32 - 104°F / 0 - 40°C
Storage Temperature -4 - 140°F / -20 - 60°C
Relative Humidity 20~90% RH (non-condensing)
Compliance
Warranty
Order Information
Regulatory: FCC, CE, RoHS
2 years
500449 HDMI 2.0 KVM HDBT Extender Kit 100m (UPC:627699004494)
HDBT Long Reach Mode: 1080P/150m (CAT6/6A/7 cable)
Output: DC 24V/1A (US/EU standard, CE/FCC/UL certified)
