Je bekijkt pagina 12 van 76
Rev. 01.07.2024
WARNING! or CAUTION! or REMEMBER!
Applicable to the given situation (general
warning sign).
Wear protective goggles.
Wear protective gloves.
Wear foot protection.
Wear protective clothing.
ATTENTION! Electric shock warning!
ATTENTION! Rotating parts, entanglement
hazard!
WARNING! Danger of crushing hands or other
extremities!
Parameter description Parameter value
Product name Tire Changer
Model MSW-
TC-750
MSW-
TC-1100HA
Rated power [W] 1100
Rated voltage [V~]/
Frequency [Hz]
230/50
Maximum tyre width
[mm]
310
Maximum rim separator
pressure [kg]
2500
Outer rim diameter [inch] 11-18 11-21
Inner rim diameter [inch] 13-22 12-25
Working pressure [bar] 6-8 8-10
Turntable torque [Nm] 1100
Maximum speed of table
rotation [rpm]
9
Dimensions [mm] 950x1050
x1830
1500x2040
x1880
Weight [kg] 169 279
Protection class I
Electrical components
protection degree
IP2X
TECHNICAL DATA
1. GENERAL DESCRIPTION
The user manual is designed to assist in the safe and
trouble-free use of the device. The product is designed
and manufactured in accordance with strict technical
guidelines, using state-of-the-art technologies and
components. Additionally, it is produced in compliance
with the most stringent quality standards.
DO NOT USE THE DEVICE UNLESS YOU HAVE
THOROUGHLY READ AND UNDERSTOOD THIS
USER MANUAL.
To increase the product life of the device and to ensure
trouble-free operation, use it in accordance with this user
manual and regularly perform maintenance tasks. The
technical data and specications in this user manual are
up to date. The manufacturer reserves the right to make
changes associated with quality improvement. The device
is designed to reduce noise emission risks to a minimum,
taking into account technological progress and noise
reduction opportunities.
PLEASE NOTE! IDrawings in this manual are for
illustration purposes only and in some details may
dier from the actual product.
The original operation manual is written in German. Other
language versions are translations from the German.
ATTENTION! Read all safety warnings and all
instructions. Failure to follow the warnings and
instructions may result in electric shock, re and/or
serious injury or even death.
The terms "device" or "product" are used in the warnings
and instructions to refer to < Tire Changer >. Do not use in
very humid environments or in the direct vicinity of water
tanks. Prevent the device from getting wet. Risk of electric
shock! Do not cover air inlets / outlets! Do not exceed the
maximum permissible operating pressure! Do not cover
the ventilation openings! Do not put your hands under
the mounting head or between the clamping jaws of the
turntable during operation. When removing the tyre, do
not put your hands into the tyre rim. Do not put your legs
or other body parts between the separator blade and the
machine body during operation. Do not stand behind the
column when using the machine (applies to the MSW-TC-
1100HA model).
2.1. ELECTRICAL SAFETY
a) The plug must t the socket. Do not modify the
plug in any way. Using original plugs and matching
sockets reduces the risk of electric shock.
b) Avoid touching earthed elements such as pipes,
heaters, boilers and refrigerators. There is an
increased risk of electric shock if the earthed device
is exposed to rain, comes into direct contact with
a wet surface or is operating in a damp environment.
Water getting into the device increases the risk of
damage to the device and of electric shock.
c) Do not touch the device with wet or damp hands.
d) Use the cable only for its designated use. Never
use it to carry the device or to pull the plug out of
a socket. Keep the cable away from heat sources, oil,
sharp edges or moving parts. Damaged or tangled
cables increase the risk of electric shock.
e) If using the device in a damp environment cannot
be avoided, a residual current device (RCD) should
be applied. The use of an RCD reduces the risk of
electric shock.
2. USAGE SAFETY
The acoustic pressure does not exceed 70 dB (A).
The product satises the relevant safety standards.
Read instructions before use.
The product must be recycled.
LEGEND
12
EN
USER MANUAL
