Je bekijkt pagina 10 van 43
Part
Number
Description Remarks
15 Check valve
16 Valve sleeve
17 Return spring
18 O type sealing ring Ø17x2,65
19 Stopper
20 Air power supply unit
21 shield of pulling
22 Gasket
23 O type sealing ring Ø16x1,8
24 O type sealing ring Ø11,2x1,8
25 U type sealing ring UN 12x22x8
26 Sealing cover
27 Cotter Ø3x20
28 Spring mandrel Ø3x15
29 Adjusting nut
30 Connecting pipe
31 Grease inlet spring
32 Steel ball sØ6
33 Piston rod
34 Spring piston
35 Socket of steel ball
36 O type sealing ring Ø24x2,4
37 Connecting pipe
38 O type sealing ring Ø14x2,65
39 O type sealing ring Ø20x2,65
40 Pump body
41 U type sealing ring UN 8x14x6
42 Check valve
43 Check valve gasket
44 Seat of grease inlet valve
45 Overow ring
46 Washer
47 Spring gasket Ø6
48 Self-locking nut M6
49 Grease inlet pipe
50 Copper gasket
51 Grease outlet connector
52 Screw
Part
Number
Description Remarks
53 Spring gasket Ø4
54 Damping spring
55 Sliding block of air supply M4x12
56 Fixing plate
57 Socket of air supply
connection
58 Paper gasket
59 Cover of air supply
60 Allen screws
61 O type sealing ring Ø46x2,5
62 Air inlet connector
63 O type sealing ring Ø45,3x2,65
64 Silencer
65 Stopper
66 Washer Ø30
67 Handle
68 Container lid
69 Hexagonal head screw M8x15
70 Pressing spring
71 Pressing disk
72 O type sealing ring Ø35x2,5
73 Wing nut
74 Yoke
75 Nut M6
76 Hexagonal head screw M6x16
77 Tank
78 Wheel
79 Washer Ø16
80 Gun
81 List of parts
82 High pressure hose
PRO-G 20
Part
Number
Description Remarks
4 Elbow
5 Cylinder cover
6 O type sealing ring Outer
diameter
Ø70x3,1
7 Self-locking nut M10
8 Piston
9 Piston gasket
10 Cylinder
11 O type sealing ring Outer
diameter
Ø16x2,4
12 O type sealing ring Outer
diameter
Ø23,6x1,8
13 Sealing screw
14 shield of pulling
15 Piston rod
16 Air inlet connector
17 Pressure regulating valve
18 Connector of pressure
regulating valve
19 O type sealing ring Outer
diameter
Ø12,6x1,8
20 Pump chamber cover
21 O type sealing ring Outer
diameter
Ø46x2,5
22 Damping spring
23 Sliding block of air supply
24 Fixing plate
25 Screw
26 Spring gasket Ø4
27 Socket of air supply
connection
28 Paper gasket
29 Piston rod
30 Spring seat
31 Grease inlet spring
32 Steel ball SØ6
33 Valve core
Part
Number
Description Remarks
34 O type sealing ring Outer
diameter
Ø19,3x2,65
35 O type sealing ring Outer
diameter
Ø25,5x2,65
36 Pump body
37 Column
38 U type sealing ring UN 8x14x6
39 Check valve
40 Check valve gasket
41 Seat of grease inlet valve
42 Overow ring
43 Washer
44 Spring gasket Ø6
45 Self-locking nut M6
46 Grease inlet pipe
47 Washer Ø30
48 Pin Ø3x15
49 Connecting column
50 Pin Ø320
51 Adjusting nut
52 Connecting pipe
53 O type sealing ring Outer
diameter
Ø24x2,4
54 Sealing cover
55 U type sealing ring UN 12x22x8
56 O type sealing ring Outer
diameter
Ø19,6x1,8
57 O type sealing ring Outer
diameter
Ø14,8x1,8
58 Gasket
59 Piston rod connector
60 Air supply
61 Copper gasket
62 Grease outlet connector
63 Stopper
64 Silencer
65 Distribution valve
18 19
Rev. 03.02.2022
Rev. 03.02.2022
Part
Number
Description Remarks
1 Pneumatic hose
2 Nut of pneumatic conduit
3 O type sealing ring Outer
diameter
Ø12,8x2,65
EN
EN
