EN
Figure 4-7
1- Cutter
4.2.3 Check the press plate
Ensure that the strapping plate is in the correct position as shown in Figure 4-8.
If the pressure plate is not in the correct position, you need to perform the following
operations:
① Pull up the belt-pressing wheel, then hold the rear edge of the belt press plate, and push
it forward to keep the groove of the belt press plate and the belt feed roller in the middle.
②Put down the pressure belt and push it forward until it cannot move, then release the belt-
pressing wheel .
Figure 4-8 - The correct position of the press plate
4.2.4 Install water storage bucket and water tank
①Insert the brush into the water storage bucket. The brush must be tilted to make it fall on
the bottom of the water storage bucket. Notice the direction of the brush when placing the brush.
The direction of the brush is shown in Figure 4-9.
Figure 4-9
1- Water storage bucket
2- Brush
②Push the entire water storage bucket along the grooves on both sides of the wall panel
until it is stuck in the positioning hole and cannot move. As shown in Figure 4-10.
