EN
of additional elements protecting the operator, there is still a slight risk of accident or injury when
using the device. Stay alert and use common sense when using the device.
3. Use guidelines
The machine is used to cut polystyrene foam into various thicknesses and shapes.
The product is intended for home use only.
The user is liable for any damage resulting from unintended use of the device.
3.1. Device description
Figure 1
1 – Foot switch. 2 – ON/OFF switch ( - On / - Off / - Foot switch mode). 3 – Temperature knob.
4 – Standly LED light. 5 – Screw for clamping the cutting wire. 6 – Circle cutting attachment. 7 – Arm.
8 – Screw for wire spool. 9 – Wire spool. 10 – Screw for spool carrier. 11 – Spool carrier. 12 – Guide slot.
13 – Guide wire. 14 – Lower wire guide. 15 – Slot for angle stop. 16 – Extension rail. 17 – Angle/mitre gauge.
