6
DE
Teile
– Nummer
Beschreibung
16 Hacken
17 Hackenunterlage
18 Hackenmutterunterlagedzi
19 Pedal
20 Bremsenstift
21 Bindeglied
22 Bundbolzen
23 Schutzfeder
24 Flache Unterlage
25 Feder
26 Pumpe
27 Pumpenprozessor
28 O-Ring Dichtung
29 Ersatzring
30 Schraube M10
31 Kleinfeder
32 Stahlkugel ф6
33 Zylindrische Kupferunterlage
34 Servomotorgestell
35 Kupferunterlage
36 Schraube M5
37 Stahlkugel ф5
38 Viereckiger Dichtungsring
39 Rűckuβverhinderer
40 Behȁlterunterlage
41 Servomotor
42 Zylinder
43 Ölschraube
44 Behȁlter
45 Y-Ring Dichtung
46 Kolben
47 O – Ring Kolbendichtung
48 Behȁlterdichtungsring
49 Behȁltermutterschraube
50 Stahlkugel ф6
51 Stahlkugelsteckdose
52 Federsicherheitsventil
Teile
– Nummer
Beschreibung
53 Schraube des Sicherheitsventils
54 O-Ring Dichtung
55 Schraube
Parameter
description
Parameter value
Product name Hydraulic
Wheel dolly
Tire wheel dolly
Model MSW-HRH-680 MSW-RH-680
Dimensions
[mm]
600x660x180 400x110x300
Range of adjust-
ment [mm]
380-660 -
Actuator stroke
[mm]
280 -
Maximum load
[kg]
680 680
Weight [kg] 36 15,5
TECHNICAL DATA
The product satises the relevant safety
standards. (MSW-HRH-680)
Read instructions before use.
WARNING! or CAUTION! or REMEMBER!
Applicable to the given situation (general
warning sign).
Wear protective goggles.
Wear protective gloves.
Wear foot protection.
ATTENTION! Danger of hand crushing.
7
Whenever "device" are used in the warnings and
instructions, it shall mean hydraulic Wheel dolly/tire wheel
dolly.
a) Do not use the device in the area exposed to strong
magnetic eld and adverse weather conditions (sub-
zero temperatures, atmospheric discharges).
b) Do not use the device to handle a dangerous load
(eg. molten metal, acid, radiant material, extremely
brittle loads).
c) Do not use the device to lift people.
d) No not work under a vehicle lifted on the dolly.
2.1. SAFETY AT THE WORKPLACE
a) Make sure the workplace is orderly and well lit.
A messy or poorly lit workplace may lead to accidents.
Try to anticipate what may happen, observe what is
going on and use common sense when working with
the device.
b) Upon discovering damage or irregular operation,
immediately switch the device o and report it to
a supervisor without delay.
c) If there are any doubts as to the correct operation
of the device, contact the manufacturer's support
service.
d) Only the manufacturer's service point may repair the
device. Do not attempt any repairs independently!
e) Children or unauthorised persons are forbidden from
entering a work station. (A distraction may result in
a loss of control over the device).
2.2. PERSONAL SAFETY
a) Do not use the device when tired, ill or under the
inuence of alcohol, narcotics or medication which
can signicantly impair the ability to operate the
device.
b) The device may be operated by physically t persons
who are able to handle the machine and properly
trained and who reviewed this operating manual and
received training in occupational health and safety
c) The device is not designed to be handled by persons
(including children) with limited mental and sensory
functions or persons lacking relevant experience and/
or knowledge unless they are supervised by a person
responsible for their safety or they have received
instructions on how to operate the device.
d) When working with the device, use common sense
and stay alert. Temporary loss of concentration whilst
using the device may lead to serious injuries.
e) Use personal protection equipment as required
for working with the device, specied in section 1
(Legend). The use of correct, approved personal
protection equipment reduces the risk of suering an
injury.
f) Do not overestimate your abilities. When using the
device keep your balance and remain stable at all
times. This will ensure better control over the device
in unexpected situations.
1. GENERAL DESCRIPTION
The user manual is designed to assist in the safe and
trouble-free use of the device. The product is designed
and manufactured in accordance with strict technical
guidelines, using state-of-the-art technologies and
components. Additionally, it is produced in compliance
with the most stringent quality standards.
DO NOT USE THE DEVICE UNLESS YOU HAVE
THOROUGHLY READ AND UNDERSTOOD THIS
USER MANUAL.
To increase the product life of the device and to ensure
a trouble-free operation, use it in accordance with this user
manual and regularly perform the maintenance tasks. The
technical data and specications in this user manual are
up to date. The manufacturer reserves the right to make
changes associated with quality improvement.
Legend
PLEASE NOTE! Drawings in this manual are for
illustration purposes only and in some details it may
dier from the actual machine.
The original operation manual is in German. Other
language versions are translations from German.
2. USAGE SAFETY
ATTENTION! Read all safety warnings and all
instructions. Failure to follow the warnings and
instructions may result in serious injury or even
death.
REMEMBER! When using the device, protect children
and other bystanders.
EN
USER MANUAL
Rev. 06.06.2022
Rev. 06.06.2022
