Je bekijkt pagina 28 van 264
EN
Part No.
Description
Quantity
Part No.
Description
Quantity
1
Base assy.
1
38
Throttle lever assy.
1
2
Housing assy.
1
39
Washer 12*2.5
10
3
Water tank
1
40
Hexagonal bolt M12*100
2
4
Blade guard
1
41
Hexagonal nut M12
1
5
Bearing bracket UCP207
1
42
Spring washer Ø12
9
6
Wheel rack module
2
43
Hexagonal bolt M12*45
8
7
Bearing bracket UCP206
1
44
Washer Ø10
18
8
Principal axis
2
45
Hexagonal bolt M10*40
3
9
Bearing bracket UCFL204
1
46
Hex flange nut M10
6
10
Jackscrew
1
47
Hexagonal bolt M16*80
1
11
Jackpost assembly.
1
48
V-belt A737
3
12
wheel handle
1
49
Flat key 7*40
1
13
Lock bracket
1
50
Flat key 8*40
1
14
Lock disk
1
51
Washer Ø10
9
15
Blade flange (outer)
1
52
Washer Ø12
1
16
Blade flange (inner)
1
53
Spring washer Ø10
13
17
Blade
1
54
Hexagonal bolt M10*20
3
18
Handle lever (pair)
1
55
Hexagonal bolt M12*20
1
19
Handle grip Ø25mm
1
56
Hexagonal bolt M10*30
10
20
Engine base assembly
2
57
Hexagonal locknut M10
7
21
Pulley, engine
1
58
Hexagonal bolt M12*120
1
22
Pulley, transmission
1
59
Hexagonal nut M12
1
23
Engine
1
60
Pointer wheel
1
24
Rear wheel
1
61
Socket head screw M8*10
1
25
Front wheel
2
62
Washer Ø8
4
26
Bearing 6203-2Z
2
63
Spring washer Ø8
7
27
Bearing 6005-2RZ
4
64
Hexagonal bolt M8*16
6
28
Belt cover
4
65
Washer Ø 8
5
29
Indicator needle
1
66
Cap nut M8
1
30
Pointer arm
1
67
Rubber mat
1
31
Cap, water tank
1
68
Screw M8*20
2
32
Nut M22
1
69
Hexagonal nut M8
2
33
Knob
2
70
Hexagonal bolt M10*45
4
34
wheel handle
1
71
Screw
1
35
Water cock
1
72
Hexagonal nut M8
1
36
Water Pipe
1
73
Pin Ø6*10
1
37
Clamp
2
74
Hexagonal bolt M8*20
2
