EN
4. Always inspect the diamond wheel before use. Do not use it if it is cracked, broken, or bent. Start the
machine carefully and check for any abnormalities.
5. Do not use the diamond wheel to cut metal. Doing so will reduce its service life or cause it to break.
6. Begin cutting only after the tool has reached its maximum rotation speed.
7. Avoid applying excessive force, which can overload the motor and reduce efficiency and service life.
Only cut concrete, tile, or stone to a depth of 100 mm or less. For deeper cuts, make 2 to 3 passes.
Cutting deeper than 100 mm in one pass reduces the diamond wheel’s service life and may cause
motor failure.
8. Do not use this machine to cut asbestos.
9. When using a cutting wheel that produces sparks, cover the dust collection adapter with a rubber cap
and always wear protective goggles.
10. Never use damaged or incorrect blade washers or bolts. These parts are specially designed for your
saw to ensure optimal performance and safe operation.
CAUTION! Always unplug the disc cutter before changing blades, servicing, cleaning, or adjusting.
3.3. Assembling the device
INSTALLING/REMOVING DIAMOND WHEEL
CAUTION! For your safety, do not attempt to cut tiles or other materials until the tool is fully
assembled. Carefully read the operating instructions beforehand to understand the machine's functions
and avoid risks from incorrect operation. Ensure the saw blade is properly installed between the inner and
outer flanges (pressure plates).
1. Turn off the tool switch and unplug it from the power socket.
2. While pressing the spindle lock button with one hand, use the provided wrench to loosen the bolt
(reverse-threaded) by turning it clockwise.
3. Remove the elastic washer and outer flange (pressure plate).
4. Place the saw blade onto the step of the inner flange (pressure plate). Note: Some blades may require
a small inner washer to ensure firm contact with the flange.
5. Reinstall the outer flange (pressure plate) onto the output shaft.
6. Place a small elastic pressure plate.
7. While pressing the self-locking button, tighten the bolt (reverse-threaded) anticlockwise with the
wrench.
8. Gently rotate the saw blade to ensure the self-locking pin has released and that the blade rotates
smoothly.
