04

support@m4sol.com | www.m4sol.com

MS-41Q USER GUIDE

Image Processing

Display mode Full screen, Quad view, PIP, POP

Max input resolution Up to 3840 x 2160@60Hz, 4:4:4 color sampling

Input resolutions

3840x2160 - 60Hz, 50Hz, 30Hz, 25Hz

1920x1080 - 60Hz, 50Hz, 30Hz, 25Hz

1280x720 - 60Hz, 50Hz, 30Hz, 25Hz

720x480 - 60Hz, 50Hz, 30Hz, 25Hz

480i, 576i - 24Hz to 60 Hz

Output color format 4:4:4, 4:2:2, 4:2:0

Max output resolution Up to 4K @60Hz, 4:4:4 color sampling

Output resolutions

4096 x 2160p - 60Hz

3840x2160 - 60Hz, 50Hz, 30Hz, 25Hz

3440x1440 - 60Hz

1920x1080 - 60Hz, 50Hz

1920x1200 - 60Hz, 50Hz

1600x1200 - 60Hz

2048x2048 - 57Hz

1280x720 - 60Hz

640x480 - 60Hz

Output color format 4:4:4

Output color depth 8 bpc (24 bit/px)

Scaler Scaling up to 4K@60Hz, 4:4:4 color sampling and downscaling as well

Video bandwidth Up to 18 Gbps

HDMI compliance HDMI 1.4 and HDMI 2.0

HDCP compliance HDCP 1.4 and HDCP 2.2

Control Methods

Front panel buttons

4 x select HDMI 1,2,3,4 input and/or audio, 6 x display layout,

1 x Audio Selection, 1 x Panel lock, 1x Standby

IR 1 x IR remote control

RS 232 / Telnet 1 x D9 Female Connector

Ethernet port 1 x RJ45

Web UI Browser / Compatible with third party control system

Specifications

The Quadview Video Processor is a simple, cost-eective video scaler designed to enable a true

4K@60Hz UHD, HD, SD video display device, virtually handling any input resolution up to 4K@60Hz.

It provides 4 HDMI inputs and 1 HDMI output.

Product hardware information

System structure Pure hardware

Startup <12 seconds

Input/Output

Input 4 x HDMI 2.0 with locking

Output 1 x HDMI 2.0 with locking
