17
PIP/PBP
1st Level Menu 2nd/3rd Level Menu Description
OFF
●
PIP (Picture in Picture) allows users to
simultaneously display multiple video sources
on one screen. One program is displayed on
the full screen at the same time as one or more
other programs are displayed in inset windows.
●
PBP (Picture by Picture) is a similar feature that
displays two input sources side-by-side on the
screen.
●
Display Switch allows users to switch between
primary and secondary input sources.
●
If there is only one signal input, the Display
Switch and Audio Switch will be grayed out.
●
Users can adjust the ratio of window division by
switching Mode 1/ 2/ Customize.
●
Activating PIP/PBP will affect:
Affected Function Function Status
»
Adaptive-Sync
»
Optix Scope
Set to OFF
»
HDMI™ CEC
Set to OFF &
unable to select
»
DisplayHDR
»
DSC
Unable to select
»
PIP: Screen Size
1:1/ 27"/ 24.5"/
16:10
»
PBP: Screen Size
Set to Auto &
unable to select
PIP Source HDMI™ 1
HDMI™ 2
DP
Type C
PIP Size Small
Medium
Large
Location Left Top
Right Top
Left Bottom
Right Bottom
Customize
Display Switch
Audio Switch
PBP Mode 1
Mode 2
Customize
Source 1 HDMI™ 1
HDMI™ 2
DP
Type C
Source 2 HDMI™ 1
HDMI™ 2
DP
Type C
Display Switch
Audio Switch
