E-6

Gas-Fired Infra-Red Tank Top Heater Operating Instructions and Owner’s Manual

NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING!NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING!NEVER LEAVE THE HEATER UNATTENDED WHILE BURNING!

LIGHTING INSTRUCTIONS

A. Beforeattemptingtolighttheheater,checkallfittingsand

connections with a soap solution. NEVER USE A MATCH TO

CHECK FOR LEAKS. Should a gas leak occur, do not attempt

to repair or use heater. Return the heater to your dealer or the

addressgivenonbackpage.

B.Fuel–Thisheatermustbeusedonlywithavaporwithdrawal

LPgasbulkcylinder.THEBULKTANKMUSTBEEQUIPPED

WITHASTANDARDPOLVALVE.

WARNING

USEHD.5PROPANEGASONLY.DONOTUSEANYOTHER

TYPEFUEL.SEEYOURPROPANEDEALERIFYOUHAVEANY

QUESTIONSREGARDINGFUEL.

C.Turntheheater’s“Hi-Med-Lo-Off”regulatorknobto“Med”

(counterclockwise).

D. To light heater, place a lit match across the mesh screen where

yousee“lighthere”onthereflector.(SeeFigure5)THEN

pushinvalvebuttononSafetyShutoffValve.Aftertheheater

islit,continuetoholdvalvebuttoninfor30seconds,then

release the button slowly. CAUTION:DONOTPUSHINVALVE

BUTTONBEFOREINSERTINGLITMATCH.NEVERSTANDIN

FRONTOFHEATERWHILELIGHTING.REPEATSTEP“D”FOR

EACHBURNER.

E. Ifburnerdoesnotlightwithin30seconds,turntheheater’s

regulatorknobto“off”(clockwise)andallowatleastfive

minutes for gas to dissipate before attempting to relight.

F. NOTE: Should the orifice become clogged as indicated by low

volumeofgaswhenoperatingon“Hi”withafullcylinder,

or should the heater fail to operate properly for any reason,

returntheheatertothedealerortheaddressgivenonback

pageforrepairorreplacement.DONOTATTEMPTTOREPAIR

ORTAMPERWITHHEATER.

G.Adjustheatoutputbyturningknobtodesiredposition.

H. DO NOT USE THIS HEATER FOR COOKING.

Figure5.

Model: MHS15T

Model: MHS30T

SHUTDOWN AND STORAGE

INSTRUCTIONS

A.Thebulkpropanetank“on-off”valveshouldALWAYSbe

completelyturned“OFF”whentheheaterisnotinuse.

B.Whenshuttingofftheheater,turntheregulatorknobonthe

heaterto“OFF”(clockwise).

C. CAUTION:Afterturningunitoff,heaterwillremainextremely

hot.Allowatleast15minutesforcoolingbeforehandlingand

storing. Detach heater from bulk tank before handling and

storage.REMEMBER–POLfittingisaleft-handthread.

D. HEATER STORAGE: Indoor storage of the heater is

permissibleonlyifthecylinderisdisconnectedandremoved

from the heater. Cylinders must be stored outdoors out of the

reach of children and must not be stored in a building, garage

or any other enclosed area. Store cylinders only in accordance

withtheStandardfortheStorageandHandlingofLiquefied

PetroleumGasesANSI/NFPA58andCSAB149.1,NaturalGas

and Petroleum Installation Code.

E. Seepage7forsparepartslist.

MAINTENANCE

A.Removethermocouple(3)retainingbracketscrewfrombackof

burnerassembly(2).Removebracket.

B. Notepositionofthermocouple(3)inretainingtabsonthe

backoftheBurnerassembly(2).Removethethermocouple.

C.Removewingbolt(18)andfiberwasher(19)thatattachedthe

safetyshut-off(6)totheburnerAssembly(2).

D. Slidethesafetyshut-off(6)fromburnerassembly(2).

E. Removeburnerorifice(20)fromthesafetyshut-off(6).

F. Cleanburnerorificewithcompressedair(80psimax).

G.Directcompressedairthroughtheburner(2)venturitube

toward the burner plenum so that dust collected on the grid

screenwillbeblownoutward.Keepfaceawayfromthegrid

screen.

H. Reassembleheaterinreverseorderofdisassembly.
