45
EN
FREE-STANDING INSTALLATION
Place the legs (6) on a flat surface and align their holes with
those on the bottom of the device. Then screw them in place
by inserting two screws into the designated locations.
USING THE APPLIANCE
1. Connect the device to the mains. When it starts up, you will hear a beep and the “--” symbol
will appear on the control panel (2).
2. On the control panel (2), press the On/Off button (2d). The display will show the default tem
-
perature setting of 25°C. The heater will start operating when the room temperature is 1 de-
gree lower than the set temperature, or will stop operating when the room temperature reach-
es the set temperature.
3. To set the temperature, press the increase button (2f) or decrease button (2g) on the control
panel (2). Each press changes the temperature by 1°C up or down. The control range is 5°C
to 55°C. After 5 seconds, the selected temperature value will be confirmed and will start to
shine continuously on the display. If no operation is performed for 1 minute, the display will
automatically enter sleep mode.
4. Press the runtime selection button (2e) on the control panel (2). The time value will start flash
-
ing on the display. Use the increase (2f) or decrease (2g) buttons to set the desired operating
time from 0 to 24 hours. After 5 seconds of inactivity, the set time is automatically confirmed.
The display will alternate between showing the set time and the temperature. If no operation is
performed for 1 minute, the display will automatically enter sleep mode.
5. To activate the parental lock, press and hold button (2f) on the control panel (2). The display
will show an “LC” symbol indicating that the lock has been activated. To switch it off, press and
hold the button (2g).
6. After turning on the device, the display will automatically turn off if no changes are made to the
settings for more than 1 minute. To reactivate it, simply press any button.
7. All appliance functions can also be controlled using the remote control (3), which has buttons
with the same function as those on the appliance control panel. In addition, the remote control
has a button to activate the energy-saving ECO mode.
WIFI CONFIGURATION AND THE “TUYA” APPLICATION CONNECTION
1. To connect the heater to your Wi-Fi network, first download the TUYA Smart app to your
smartphone by searching for ‘TUYA Smart’ in the Google Play Store or Apple App Store.
2. Download and install the app. If you do not already have a Smart Life account, register by
selecting “Register” and follow the on-screen instructions.
3. The device will automatically recognise the user’s country, but it can be manually changed if
necessary. Then enter your telephone number or email address. If you choose to register using
your phone number, you will receive an SMS verification code – enter it and then create an
account. If registering via email address, simply set a password and complete the registration
process.
4. To add a heater to the app, the device must first be switched to Wi-Fi connection mode. To
do this, connect the heater to a power source. When it starts up, you will hear a beep and the
“--” symbol will appear on the control panel (2). Press and hold the time selection button (2e).
The Wi-Fi indicator (2c) will start flashing, indicating that the device is attempting to connect to
the network. You can now connect to Wi-Fi and add the heater to the TUYA APP using your
