EN
28
In its horizontal section, the pipe must be inclined slightly upwards (around 10°) to facilitate the
evacuation of air. If the hood is equipped with carbon filters, they must be removed.
Connect the hood to the exhaust ventilation with a pipe whose diameter matches the diameter
of the hood’s exhaust (flange).
The use of lower diameter pipes will reduce the performance and dramatically increase the
hood’s operating noise.
The manufacturer shall not be responsible for this.
The pipe for evacuating fumes must be as short as possible.
- The pipe should have as few bends as possible (max. bend angle: 90°).
- The pipe’s diameter must not vary radically.
- The pipe’s internal surface must be as smooth as possible.
- The pipe’s material must conform to the standards in force.
HOOD OPERATING IN EXTRACTION MODE
A carbon filter must be installed to be able to use the hood in extraction mode. Carbon filters
are available from our vendors.
The drawn air is purified from grease and odours before being returned to the room via the
grate in the stack’s upper cover.
HOOD INSTALLATION
The minimal distance between the surface on which vessels are placed on the heating device
and the hood’s lowest part should not be less than 55 cm for electrical stoves and not less than
65 cm for gas or dual-type stoves.
If the gas stove manual prescribes a bigger distance, this value must be observed.
The hood is equipped with installation screws suitable for most types of walls and ceilings.
However, it is still necessary to consult a qualified technician to make sure the materials of the
wall or ceiling are adequate to use with such screws. The wall or the ceiling must be sufficiently
strong to support the hood’s weight.
CAUTION! Failure to tighten the screws and installation devices according to the instruction
may lead to electrical risks.
ELECTRICAL CONNECTIONS
The mains voltage must match the voltage indicated on the plate inside the hood. The hood is
equipped with a plug that must be connected to a socket satisfying the relevant standards and
placed in a location that is easy to access, even after the installation.
CAUTION! Before reconnecting the hood to the mains and verifying that it operates cor
-
rectly, make sure the power cord is properly connected. The hood is equipped with a special
power cord.
If this cord is damaged, a new one should be purchased from the manufacturer or the vendor.
