22
EN
OVERVIEW
Locks
If your Refrigerator is fitted with a lock, keep the key out of reach and not in the vicinity of the appliance to prevent children
being entrapped. When disposing of an old Refrigerator, break off any old locks or latches as a safeguard.
Freon-free
The freon-free refrigerant (R600a) and the foaming insulation material (cyclopentane) that is environmentally friendly are used
for the refrigerator, causing no damage to the ozone layer and having a very small impact on the global warming. R600a is
flammable, and sealed in a refrigeration system, without leakage during normal use. But, in case of refrigerant leakage due to
the refrigerant circuit being damaged, be sure to keep the appliance away from open flames and open the windows for
ventilation as quickly as possible.
NAMES OF THE PARTS
WARNING: Never touch the interior of the Freezer Chamber or frozen foods inthecompartment with wet hands as this
could result in frost bite.
TRANSPORTATION INSTRUCTIONS
The appliance should be transported only in a vertical upright position. The packing as supplied must be intact during
transportation.
If during transport, the product has been transported horizontally, it must only be laid on its left-hand side (when facing the
door front) and it must not be operated for at least 4 hours to allow the system to settle after the appliance is brought back to
upright position.
1. Failure to comply with the above instructions could result in damage to the appliance. The manufacturer will not be held
responsible if these instructions are disregarded.
2. The appliance must be protected against rain, moisture, and other atmospheric influences.
IMPORTANT: Care must be taken while cleaning / carrying the appliance to avoid touching the condenser metal wires at the
back of the appliance, as you might injure your fingers and hands or damage your product.
IMPORTANT:This appliance is not designed for stacking with any other appliance. Do not attempt to sit or stand on top of your
appliance as it is not designed for such use. You could injure yourself or damage the appliance.
IMPORTANT: Make sure that mains cable is not caught under the appliance during and after carrying / moving the appliance,
to avoid the mains cable becoming cut or damaged.”
When positioning your appliance take care not to damage your flooring, pipes, wall coverings etc. Do not move the appliance
by pulling by the lid or handle. Do not allow children to play with the appliance or tamper with the controls. Our company
declines to accept any liability should the instructions not be followed.
INSTALLATION INSTRUCTIONS
1. If possible, avoid placing the appliance near cookers, radiators or in direct sunlight as
this will cause the compressor to run for long periods. If installed next to a source of
heat or refrigerator, maintain the following minimum side clearances:
From Cookers 4" (100 mm)
From Radiators 12" (300 mm)
From Fridges 4" (100 mm)
2. Make sure that sufficient room is provided around the appliance to ensure free air
circulation. Ideally, A space of no less than 10cm must be left around the freezer, and
ensure you allow gaps as shown in the below diagram.
3. The appliance should be located on a smooth surface.
3
Lock
Control Panel
*
* Exact quantity of the
baskets depends on model
Handle
Hinge
Basket*
Lock
Control Panel
Cabinet
Drain outlet
Adjustable foot
* Exact quantity of the baskets depends on model
Note: Above picture is for reference only.
INSTALLATION
POSITIONING
Install this appliance at a location where the ambient temperature corresponds to the cli
-
mate class indicated on the rating plate of the appliance:
For refrigerating appliances with climate class:
– extended temperate: ‘this refrigerating appliance is intended to be used at ambient tem
-
peratures ranging from 10 °C to 32 °C (SN);
– temperate: ‘this refrigerating appliance is intended to be used at ambient temperatures
ranging from 16 °C to 32 °C (N);
– subtropical: ‘this refrigerating appliance is intended to be used at ambient temperatures
ranging from 16 °C to 38 °C (ST);
– tropical: ‘this refrigerating appliance is intended to be used at ambient temperatures
ranging from 16 °C to 43 °C (T);
LOCATION
The appliance should be installed well away from sources of heat such as radiators, boilers,
direct sunlight etc. Ensure that air can circulate freely around the back of the cabinet. To
ensure best performance, if the appliance is positioned below an overhanging wall unit,
the minimum distance between the top of the cabinet and the wall unit must be at least
100 mm. Ideally, however, the appliance should not be positioned below overhanging wall
