13
13
Installing the blade assembly in the jar (*depending
on the model)
• Fitting the removable blade assembly (*depending
on the model
Cf. Fig. 11 a; b; c):
1. Make sure that the seal is properly positioned over
the blade assembly
(Cf. 11.a)
.
2. Pick up the blade assembly using a cloth and place
it in its slot at the bottom of the jar, making sure
you carefully position the blade assembly grips in
the jar grooves
(Cf. 11.b)
.
3. Return the jar keeping the blade assembly in its slot
(Cf. 11.c)
.
4. Lock the blade assembly section using the locking
ring
(Cf. 11.c)
.
• Dismounting the removable blade assembly
(*depending on the model
Cf. Fig. 11.d)
:
Place the jar on a work surface.
1. Use a cloth to help hold the blade assembly.
2. Return the jar while holding the blade assembly.
3. Turn the locking ring to unlock the blade assembly.
Warning: the blades are very sharp: handle them
with care so as not to injure yourself whilst fitting,
dismounting and cleaning the jar and the blade
assembly.
In the event of incorrect positioning or locking of one
or the other (Cf. Fig. 5 and 6), the lock sign
START
START
starts
to flash when you activate a function.
Your appliance has 3 operating modes:
• Automatic program mode: temperature, cooking
and mixing times are pre-programmed to make
soups and to carry out automatic steam cooking.
• Manual Mode: personalised adjustments in
temperature and cooking time for one use can be
made according to your preferences.
• Blender Mode: select the motor speed without using
the cooking function to make some tasty smoothies
or cocktails.
Positioning of the jug and the lid unit
• Before using for the first time, wash all the
accessories (D, E and F) in hot soapy water except
for the motor unit (A).
• Make sure that all packaging is removed before
operating the appliance.
• Place the seal on the lid (Cf. Fig. 1).
• To steam cook, put the basket with the sliced
vegetables in position and fill up the jug with 0.5
litres of cold water without exceeding the bottom
of the basket
(Cf. Fig.13 a; b; c).
• Position the lid (E) on the jar (D) (Cf. Fig. 2), lock the
lid without pressing by turning it in the direction of
the arrow (Cf. Fig. 3).
• Position the blender jar (D) on the motor unit (A)
until you hear it click (Cf. Fig. 4).
• The appliance only starts up once the jug and
lid are correctly in place and are locked onto the
motor unit.
BEFORE FIRST USE
appliance and its cord out of
the reach of children less than 8
years old.
• Children must not use the
appliance as a toy.
• This appliance can be used
by persons with reduced
physical, sensory or mental
abilities or lacking experience
or knowledge on the condition
that they have been given
supervision or instructions
for using the appliance in a
safe way and understand the
dangers involved.
AFTER-SALES
• For your safety, do not use
accessories or spare parts,
other than those provided by
authorised service centres.
• Any operation other
than cleaning or routine
maintenance should be
performed by an approved
service centre.
