* According to model: this is either equipment specific to certain models or available as an optional accessory
CONNECTING THE CABLE AND STARTING YOUR APPLIANCE
• Unravel the cable completely, connect your appliance, - fig.6 and press the On/off pedal. (2) - fig. 7.
• Adjust the power of the vacuum : with the mechanical power adjustment : open the slider control to
manually reduce the suction power, except on fragile surfaces - fig. 8.
STORING AND TRANSPORTING THE APPLIANCE
• After use, stop the vacuum cleaner by pressing on the On/off pedal (2) and disconnect it. fig. 9. Store
the cable by pressing on the pedal of the cable winder. (3) - fig. 10.
• In the vertical position, place the all floor nozzle (21) in its storage position under the appliance (1b) -
fig. 11.
• In the horizontal position, place the all floor nozzle (21) in its storage position behind the appliance.
(1a)- fig. 12.
• You can transport the appliance easily, thanks to its carrying handle (6).
5. CLEANING AND MAINTENANCE
Important : Always switch off and disconnect your vacuum cleaner before maintenance or cleaning.
CHANGING THE BAG
• The “bag full” indicator (4) tells you that the bag needs to be emptied or is saturated. If you notice a de-
crease in the efficiency of your appliance adjust the power to maximum and keep the suction nozzle lif-
ted off the floor. If the indicator stays red, replace the bag.
• Take the flexible tube (17) out of the vacuum outlet. (9)- fig. 2.
• Open the cover (8) of your vacuum cleaner- fig. 13.
a) If your vacuum cleaner is equipped with a paper bag :
• Remove the bag support (14) from the bag compartment (7)- fig.14, then lift the paper bag (16a) from its
support (14) by sliding on the rails (14) fig.15.
• Throw the bag in the bin. fig. 16.
• Position a new bag (14) on the bag support fig.17, then, with the help of the rails on the bag support
(15) place it in the bag compartment- fig.18.
• Make sure the bag is properly positioned before closing the cover. (8).
b) If your vacuum cleaner is equipped with a textile bag* :
• Remove the bag support (14) from the bag compartment (7)- fig.19, then lift the textile bag (16b) away
from its support (14) by sliding it along the rails fig.20.
• Open the bag with the zip- fig. 21, then empty it in the bottom of a bin- fig. 22.
• Clean the bag with clear water- fig. 23.
• Leave to dry at least 24 hours (Do not replace the bag until it is completely dry) - fig. 24.
• Ensure that the zip is properly closed -fig.25 before putting the bag back in place.
CHANGING THE MICRO FILTER* (ref : MT0005 01)
Important : Change the microfilter * every 6 months.
• Open the lid (8) of your vacuum cleaner -fig. 13.
• Open the grill protecting the motor. (11)- fig. 26.
• Pull out the micro filter* (12)-fig.26-27.
• Put the micro filter* (12) in the bin -fig. 28 and replace with a new one (ref. MT0005 01)- fig. 29.
• Place the pins in the notches- fig. 29.
• Adjust the micro filter* behind the motor protection grill (11) -fig. 30.
• Make sure the micro filter* is properly positioned (12) before closing the cover. (8).
CLEANING THE (H)EPA* FILTER CASSETTE (ref. RS-RT9926)
Clean the (H)EPA* filter cassette every 6 months (according to frequency of use).
EN
902739_mini-space_902739 01/02/11 14:28 Page13
