EN
1110
A Motor unit
B 1 Locking ring
2 Powelix blades
3 Seal
C 1 On-the-Go bottle 700 ml
2* On-the-Go bottle 400 ml
D 1 On-the-Go bottle lid 700 ml
2* On-the-Go bottle lid 400 ml
E Screen
1 Sauce function
2 Smoothie function
3 On/Off button
4 Ice crush function
5 Silence function
6 Pulse function
7 Auto clean function
8 Cold soup function
9 Plant-based milk function
10 Dips function
11 Screen
F Cleaning brush
G* Chopper accessory
CAUTION
The safety instructions are part of the appliance. Read these instructions carefully before using your new appliance
for the first time. Keep them in an accessible place so that you can refer to them later. The appliance can only
operate if the bottle is correctly positioned on the motor unit (A).
BEFORE USING YOUR APPLIANCE FOR THE FIRST TIME
Before using your appliance for the first time, wash parts that come into contact with food (bottle, etc.) with hot
soapy water, then rinse.
WARNING: Do not immerse the appliance in water (neither the motor unit nor the blades unit (A and B2)).
Never put the motor unit (A) under running water. Clean the appliance with a damp cloth and dry it carefully.
The blades are extremely sharp.
Check that all parts of the packaging and labels have been removed before using the appliance.
ASSEMBLING AND FITTING THE ON-THE-GO BOTTLE
Moisten the seal (B3) (even if it is already mounted on the blade unit (B2)) by quickly passing it under water.
Be careful to correctly fit the seal (B3) back onto the blades unit (B2). (Fig. 1).
Add the ingredients into the bottle without exceeding the maximum level indicated:
* 700 ml for the 700 ml bottle
* 400 ml for the 400 ml bottle
Warning: Do not pour boiling liquids (over 70°C/158°F) into the bottle.
Place the blade holder with its seal (B3+B2) on the locking ring (B1) (Fig. 2). Hold the bottle and screw the locking
ring onto it. (Fig. 4). Turn the bottle (C) upside down and screw the locking ring with blades onto the base of the
motor unit (Fig. 5).
USING YOUR APPLIANCE
Put the appliance on a flat, stable, heat-resistant surface away from heat sources or water.
Add your ingredients to the bottle, screw in the blades and place the bottle correctly on the motor unit. Plug in your
appliance Select your program (E) (Fig. 7) and press the Start/Stop button (E3) (Fig. 8). You can refer to the program
table below to help you choose the right program for your recipe.
The appliance starts. The duration of the program until the end of its execution is displayed on the screen (E11).
At the end of each automatic program, the appliance stops automatically and beeps 4 times. To stop your appliance
before the automatic program ends, press the Start/Stop button (E3).
DESCRIPTION
Please note : Your appliance has a Pulse function (E6). It can be used manually when no program is running. Press
and hold the button to mix. Do not exceed 3 minutes of consecutive use.
WARNING : In case of overheating, your product is equipped with a thermal fuse that will automatically stop the
appliance.
After 3 minutes without use, your appliance will beep twice and start a standby mode. To switch on your appliance
again, press the Start/Stop button (G).
Please note: Some coloured foods can stain the inside of the bottle (e.g. carrots). To remove stains, you can use a
cloth and a little vegetable oil.
AUTOMATIC PROGRAMS AVAILABLE
Automatic
programs
Time
Sample recipe for the 700 ml
bottle
Sample recipe for the 400 ml
bottle*
Sauce
1 min
Pesto verde
-
30 g basil
10 g garlic
20 g parmesan
120 ml olive oil
Smoothie 1 min
Vitality blend
400 ml water
150 g carrots
75 g banana
75 g celeriac
220 ml water
90 g carrots
45 g banana
45 g celeriac
Ice crush
30 secs
Ice
5 ice cubes 2x2x2 cm
(100g)
5 ice cubes 2x2x2 cm
(100g)
Cold soup
1 min
Gazpacho
250 g tomatoes
80 g red pepper
125 g cucumber
40 g onion
90 ml water
10 ml vinegar
10 g concentrated tomato paste
-
Plant-
based
milk
2 mins
Almond milk
60 g almonds
640 ml water
-
Dips
1 min
Hummus
-
265 g chickpeas
15 g tahini
10 g garlic (2 cloves)
40 g lemon juice
40 g olive oil
65 ml water
