ABOUT THE V4HD

15

■

1 x HDMI output (4:2:2 10-bit, YCbCr or RGB)

■

Support for DVI output with HDMI-to-DVI

adapter (sold separately)

■

1 x HD component in and out (10-bit, YPbPr or

RGB) on independent BNCs

■

1 x SD component in and out (10-bit, YPbPr or

RGB) on independent BNCs

■

1 x composite in and out (10-bit)

■

1 x S-video in and out (10-bit)

■

12-bit A/D and D/A converters on all analog

video in/out with up to 8x oversampling

VIDEO FORMATS

■

SD — 576i25 (PAL), 480i29.97 and 486i29.97

(NTSC)

■

HD — 720p23.976, 720p24, 720p25, 720p29.97,

720p30, 720p50, 720p59.94, 720p60, 1080p23.976,

1080p24, 1080p25, 1080p29.97, 1080p30,

1080PsF23.976, 1080PsF24, 1080PsF25,

1080PsF29.97, 1080PsF30, 1080i25, 1080i29.97,

1080i30

■

Supported Final Cut Pro HD formats — Apple

ProRes or DVCProHD 720p at all eight frame rates

listed above, plus full-raster (1920 x 1080) ProRes

or DVCProHD 1080 (1280 and 1440 rasters) at all

1080 frame rates listed above

■

Supported Final Cut SD formats —

Uncompressed 8-bit and 10-bit, DVCPro and

DVCPro 50 at 480p23.976, 480i29.97 and 576i25

■

480p23.976 SD capture and playback with

hardware pull-down insertion/removal

AUDIO I/O

■

32 channels of simultaneous audio input and

output

■

8 channels of analog in/out at all standard

sample rates from 44.1 to 192kHz

■

4 x XLR analog in/out — 4-channel direct

connection without a breakout cable

■

8 channels of AES/EBU digital in/out at sample

rates up to 96kHz

■

2 x AES/EBU connectors — 4-channel direct

connection without a breakout cable

■

8-channel HD-SDI and SD-SDI embedded

audio in/out, 24-bit at 44.1 or 48kHz

■

8-channel HDMI embedded audio output,

24-bit at 44.1 or 48kHz

■

Embeds SDI and HDMI multi-channel audio

streams; de-embeds SDI audio input

■

8-channel ADAT optical digital audio in/out —

includes a second bank of optical connectors for

8-channel operation at sample rates up to 96kHz

■

Flexible 8-channel sample rate conversion —

apply rate conversion to any 8-channel digital

input or output bank, including AES/EBU,

embedded and optical

■

Front panel headphone jack with dedicated

volume control

■

Programmable front panel volume control for

up to 32 audio outputs — control output level for

any/all outputs, from stereo main outs to 7.1

surround to all 32 outs

■

CueMix FX built-in monitor mixer —

32-channel, 16-bus mixer for monitoring live

inputs from cameras, mic preamps or other audio

sources with virtually no delay.

■

Set up send/return loops to digital mixers and

outboard audio processing.

■

Multiple CueMix FX mixes — create 16 separate

stereo monitor mixes (4 stereo at 176.4 or 192kHz)

for main outs, headphones, outboard gear send/

return loops, etc.
