Specications
Model Bronze 50 7G Bronze 300 7G Bronze Centre 7G
System Format
2-Way
2.5-Way 2-Way
Frequency Response,
In-Room (-6dB)
41 Hz - 30 kHz 34 Hz - 30 kHz 50 Hz - 30 kHz
Sensitivity
(2.83v @ 1m, Free-Field)
86 dB 88 dB 88 dB
Sensitivity
(2.83v @ 1m, Installed)
N/A N/A N/A
Nominal Impedance 8 Ohms 8 Ohms 8 Ohms
Minimum Impedance
(20Hz to 20kHz)
4.0 Ohms @ 200 Hz 4.4 Ohms @ 38 Hz 4.3 Ohms @ 200 Hz
Maximum Peak SPL
(AES75, Z-weighted)
112 dB 118 dB 119 dB
Continuous Power
Handling (CTA 426-B)
100 W 150 W 120 W
Recommended
Amplifier Power
(RMS, Music Signal)
50 - 200 W into 4 Ohms
30 - 100 W into 8 Ohms
75 - 300 W into 4 Ohms
40 - 150 W into 8 Ohms
60 - 240 W into 4 Ohms
30 - 120 W into 8 Ohms
Bass Alignment PortedHiVe II PortedHiVe II Sealed
Port Tuning Frequency 47 Hz 38 Hz N/A
Crossover Frequency LF/HF: 3.0 kHz LF/MF: 470 Hz
MF/HF: 2.6 kHz
LF/HF: 2.7 kHz
Drive Unit Complement 1 x 6" C-CAM bass mid driver
1 x 25 mm C-CAM Gold Dome tweeter
2 x 6" C-CAM bass mid driver
1 x 25 mm C-CAM Gold Dome tweeter
2 x 6" C-CAM bass mid driver
1 x 25 mm C-CAM Gold Dome tweeter
Available Finishes White
Black
Walnut
White
Black
Walnut
White
Black
Walnut
External Dimensions
with all accessories
fitted (H x W x D)
335 x 185 x 328 mm
(13
3/16
x 7
5/16
x 12
7/8
")
1005 x 269 x 392 mm
(39
9/16
x 10
5/8
x 15
7/1 6
")
205 x 500 x 229 mm
(8
1/16
x 19
11/16
x 9 ")
Weight (Product, Each) 6.4 kg
(14 lb 2 oz)
15.6 kg
(34 lb 6 oz)
7.9 kg
(17 lb 7 oz)
Sold As Pair Pair Single
Model Bronze On-Wall 7G Bronze AMS 7G Dolby
Atmos
®
Enabled Speaker
System Format 2-Way
2-Way
Frequency Response,
In-Room (-6dB)
42 Hz - 30 kHz 83 Hz - 30 kHz
Sensitivity
(2.83v @ 1m, Free-Field)
N/A 86 dB
Sensitivity
(2.83v @ 1m, Installed)
88 dB N/A
Nominal Impedance 8 Ohms 8 Ohms
Minimum Impedance
(20Hz to 20kHz)
4.7 Ohms @ 17 kHz 3.7 Ohms @ 10 kHz
Maximum Peak SPL
(AES75, Z-weighted)
122 dB 110 dB
Continuous Power
Handling (CTA 426-B)
100 W 60 W
Recommended
Amplifier Power
(RMS into, Music Signal)
50 - 200 W into 4 Ohms
30 - 100 W into 8 Ohms
30 - 120 W into 4 Ohms
10 - 60 W into 8 Ohms
Bass Alignment Ported Sealed
Port Tuning Frequency 47 Hz N/A
Crossover Frequency LF/HF: 3.0 kHz LF/HF: 4.8 kHz
Drive Unit Complement 1 x 6" C-CAM bass mid driver
1 x 25 mm C-CAM Gold Dome tweeter
1 x 4" C-CAM mid-range driver
1 x 25 mm C-CAM Gold Dome tweeter
with optimised waveguide
Available Finishes White
Black
Walnut
White
Black
Walnut
External Dimensions with
all accessories fitted
(H x W x D)
465 x 300 x 135 mm
(18
5/16
x 11
13/16
x 5
5/16
")
173 x 185 x 302 mm
(6
13/16
x 7
5/16
x 11
7/8
")
Weight (Product, Each) 7.0 kg
(15 lb 7 oz)
3.1 kg
(6 lb 13 oz)
Sold As Single Pair
