Je bekijkt pagina 29 van 87
Supported Functional Modules (Pre-mounted on
Front Plate)
Functional Module Order Code Remark
Functional MultiSense mod-
ule (pre installed)
Mx-F-MSA with PIR sensor, temperature sensor, illu-
mination sensor and status LED
Connector Box RJ45
Interface Properties
Network 100/1000 Mbps
Overvoltage Protection max. 4 kV on the PoE network cabling
Allowed cable dimensions
for cables connected to the
PCB terminals
Conductor cross section
AWG 20 - 26
Rigid 0.14mm
2
- 0.5mm
2
Flexible 0.14mm
2
- 0.5mm
2
Flexible with ferrule 0.25mm
2
- 0.34mm
2
Line In Standard Line In: (0dB) Vrms=1V
Line Out Headphones with 20mW @ 16 Ohm or 32 Ohm.
Audio inputs as a Line Out function to 10k Ohm impedance of receiver. Audio
level while connected to 10k Ohm equals -10dbV
IN / OUT INPUT
n
Contact Closure (no galvanic isolation necessary) or up to 50V AC/DC
n
max. length for cables: 50m
OUTPUT
n
requires pull-up resistor and external power supply (10mA / max. 50V DC
- no AC)
n
Output may be loaded with max. 50mA
n
max. length for cables: depends on loop impedance of the connected
cable.
Technical Specifications
Supported Functional Modules (Pre-mounted on Front Plate)
29 / 87
