Supported Thermal Sensor Modules (Pre-mounted on Thermal
Front Plate)
CAUTION! Do not remove or replace the pre-installed thermal sensor module included in the scope of deliv-
ery. Otherwise, the camera will lose the EN54 certification.
Sensor Module Order Code
CIF Thermal Radiometry
45° x 35°
Mx-O-M73TB-336R100
CIF Thermal Radiometry
25° x 19°
Mx-O-M73TB-336R150
CIF Thermal Radiometry
17° x 13°
Mx-O-M73TB-336R280
VGA Thermal Radiometry
90° x 69°
Mx-O-M73TB-640R050
VGA Thermal Radiometry
69° x 56°
Mx-O-M73TB-640R080
VGA Thermal Radiometry
45° x 37°
Mx-O-M73TB-640R100
VGA Thermal Radiometry
32° x 26°
Mx-OM73TB-640R150
The Thermal Radiometry (TR) variants automatically alarm when the temperature exceeds or falls below
defined limits. This is crucial for the detection of fire or heat sources. Up to 20 different temperature events
can be configured simultaneously in so-called TR windows or over the complete sensor image over a tem-
perature range of High Sensitivity: –40 to 170°C/–40 to 320°F –- Low Sensivity: -40 to 550°C/–40 to 1022°F .
Features Thermal Image Sensors
Feature Properties
Thermal sensitivity Typ. 50 mK, IR range 7.5 to 13.5 μm
Temperature measurement
range (adjustable)
High Sensitivity: –40 to 170°C/–40 to 320°F –- Low Sensivity: -40 to 550°C/–40
to 1022°F
Technical Specifications
Sensor Modules
27 / 87
