64
MUZ-GL24NA
MUZ-GL24NAH
MUY-GL24NA
Fin temperature
thermistor/RT64
(CN673)
Ambient temperature
thermistor/RT65
(CN672)
Discharge temperature
thermistor/RT62
(CN671)
Defrost thermistor
/RT61 (CN671)
(MUZ)
Output to
drive outdoor
fan motor
(CN932)
Outdoor heat exchanger
temperature thermistor
/RT68 (CN671)
Fuse (F901)
T3.15AL250V
Fuse (F880)
T3.15AL250V
Expansion valve/LEV
(CN724)
Jumper wire for
changing defrost
setting (JS)
Jumper wire for
pre-heat control
setting (JK)
Fuse (F601)
T3.15AL250V
Signal of out-
door fan motor
(CN931)
R.V. coil/21S4
(CN602)
208/230 V AC (MUZ)
294 - 370 V DC
JP715 (+)
JP30 (-)
LED
-4 14 32 50 68 86 104
0
10
20
30
40
50
60
70
80
90
100
Temperature (°F)
Defrost thermistor (RT61) (MUZ)
Ambient temperature thermistor (RT65)
Outdoor heat exchanger temperature thermistor (RT68)
32 50 68 86 104 122 140 158 176
0
20
40
60
80
100
120
140
160
180
200
Temperature (°F)
Fin temperature thermistor (RT64)
Resistance(k )
Resistance(k )
Temperature (°F)
Discharge temperature thermistor (RT62)
Resistance (kΩ)
0
100
200
300
400
500
600
700
800
32 50 68 86 104 122 140 158 176 194 212 230 248
Heater connector
(CN601)
(MUZ-GL24NAH)
OBH733J
