EN
EN-7
In the following cases, stop using the air conditioner and consult your dealer.
• When water leaks or drips from the indoor unit.
• When the operation indicator lamp blinks.
• When the breaker trips frequently.
• The remote control signal is not received in a room where an electronic ON/
OFF type fl uorescent lamp (inverter-type fl uorescent lamp, etc.) is used.
• Operation of the air conditioner interferes with radio or TV reception. An ampli-
fi er may be required for the affected device.
• When an abnormal sound is heard.
• When any refrigerant leakage is found.
WHEN YOU THINK THAT
TROUBLE HAS OCCURRED
SPECIFICATIONS
Indoor Outdoor
Cooling
Upper limit
32°C DB
23°C WB
46°C DB
—
Lower limit
21°C DB
15°C WB
-10°C DB
—
Heating
Upper limit
27°C DB
—
24°C DB
18°C WB
Lower limit
20°C DB
—
-20°C DB
-21°C WB
Note:
Rating condition
Cooling — Indoor: 27°C DB, 19°C WB
Outdoor: 35°C DB
Heating — Indoor: 20°C DB
Outdoor: 7°C DB, 6°C WB
Guaranteed operating range
Wi-Fi
®
interface
Model MAC-577IF2-E
Input Voltage DC12.7 V (from indoor unit)
Power consumption MAX. 2 W
Size H×W×D (mm) 73.5×41.5×18.5
Weight (g) (including cable) 46
Transmitter power level (MAX.) 20 dBm @IEEE 802.11b
RF channel 1ch ~ 13ch (2412~2472 MHz)
Radio protocol IEEE 802.11b/g/n (20)
Encryption AES
Authentication WPA2-PSK
Software Version XX.00
For Declaration of Conformity, please go to the website below.
http://www.mitsubishielectric.com/ldg/ibim/
Model
Indoor MSZ-AY25VGK(P) MSZ-AY35VGK(P) MSZ-AY42VGK(P) MSZ-AY50VGK(P)
Outdoor MUZ-AY25VG(H) MUZ-AY35VG(H) MUZ-AY42VG(H) MUZ-AY50VG(H)
Function Cooling Heating Cooling Heating Cooling Heating Cooling Heating
Power supply ~ /N, 230 V, 50 Hz
Capacity kW 2.5 3.2 3.5 4.0 4.2 5.2 5.0 5.5
Input kW 0.60 0.78 0.99 1.03 1.30 1.39 1.54 1.47
Weight
Indoor kg VGKP: 11, VGK: 10.5
Outdoor kg 27 28.5 34 40.5
Refrigerant fi lling capacity (R32) kg 0.55 0.55 0.70 1.00
IP code
Indoor IP 20
Outdoor IP 24
Permissible excessive
operating pressure
LP ps MPa 2.77
HP ps MPa 4.17
Noise level (SPL)
Indoor (Super High/
High/Med./Low/Silent)
dB(A)
42/36/30/
24/18
45/39/34/
24/18
42/36/30/
24/18
45/38/31/
24/18
42/38/34/
29/21
45/40/35/
29/21
44/40/36/
33/28
48/43/38/
33/28
Outdoor dB(A) 47 48 49 50 50 51 52 52
DB: Dry Bulb
WB: Wet Bulb
Indoor specifi cation for multi connection REGULATION (EU) 2016/2281
Model Indoor MSZ-AY25VGK(P) MSZ-AY35VGK(P) MSZ-AY42VGK(P) MSZ-AY50VGK(P)
Capacity
Cooling
Sensible kW 2.30 3.08 3.23 3.70
Latent kW 0.20 0.42 0.97 1.30
Heating kW 2.90 4.00 4.80 5.70
Input kW 0.026 0.026 0.032 0.032
Noise level
(Sound power level)
Super High/High/Med./Low/Silent dB(A) 57/51/45/39/34 57/51/45/39/34 57/53/49/44/36 58/54/50/47/42
