Mount the electrical box in the wall in the place where the temperature controller is to be installed,
remember to lead the mains power cables to the box,
Make a groove in the wall and in the floor for the protective conduit,*
Clean the floor thoroughly and then install the protective conduit with the floor temperature sensor.
Remember that the temperature sensor must be located directly under the influence of the heating mat, run
in parallel between the heating cables or between two strips of the mat, the sensor cable must not intersect
with the heating cable,*
On a properly cleaned floor surface, spread the insulating underlay,
In the place where the floor temperature sensor is located, cut a small piece of underlay,*
Make the first measurement of the resistance of the heating wire and insulation. The measurement of the
resistance of the heating cable should be similar to the parameters shown in the table on the next page.
The measurement result should be entered in the warranty card. The insulation resistance should be around
10Ω.
Spread the heating mat on the floor of the room in accordance with the previously prepared design.
Remember that the heating cable must not be cut. However, it is advisable to cut the mounting mat in order
to adjust the arrangement of the heating mat to the design and shape of the room. By properly cutting the
mat, we can change the direction of the mat, avoid obstacles in the room, and even reverse the direction
of the mat, which will allow for the perfect arrangement of parallel stripes. The possibilities of cutting the
mesh, depending on the given situation, are presented on page 26.
It is recommended to take photographs of the heating mats laid out on the floor.
Connect the individual strips of the mat with aluminum tape.
Insert the power cords into the protective pipe, and then into the flush-mounted box, where the temperature
controller will be installed.
At this stage, a second measurement of the system resistance should be made. The result should be entered
in the warranty card. If the second measurement differs significantly from the first and from the data in the
table, it means that the system was damaged during the laying of mats in the room.
Turn on the heating mat to check if it works properly. The heat should be felt within a few minutes.
Start laying the floor panels. Remember to perform all preparatory activities related to cutting or shortening
the panels outside the underfloor heating installation area
After laying the floor covering, make a final measurement of the resistance of the system. Record the result
in the warranty card. If the measurement differs significantly from the previous ones and from the data in
the table, it means that the system was damaged during the laying of the floor panels.
In the previously prepared box with the mat power cables, mains power cables and optionally with the
temperature sensor cable, install the temperature regulator. During installation, follow the installation
instructions provided by the thermostat manufacturer.*
INSTALLATION OF THE MAL-160 HEATING MAT:
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
14.
15.
Attention! The system should be connected by a qualified electrician.
*The wired floor temperature sensor is not configured with every temperature controller.
