Outline of the room with dimensions,
Marking of places of permanent development,
Locations of doors and windows,
Laying mats with their length and strength marked,
Thermostat location,
Location of the floor temperature sensor (if present).
Before commencing assembly work, a detailed layout plan of the system should be prepared in a
specially designated part of the manual. Failure to follow the detailed plan may result in loss of
warranty coverage.
Include:
TEMPERATURE REGULATOR AND FLOOR TEMPERATURE
The regulator should be placed at a height of about 150 cm from the floor, in a place free of
drafts, out of direct sunlight.
Most thermostats have a wired floor temperature sensor, which should be placed in the optional
protective guide conduit and placed centrally under the regulator at a distance of about 50cm
from the wall.
The thermostat should be installed in a special mounting box.
Regulators should not be installed in damp rooms.
FLOOR SENSOR INSTALLATION
Protective conduits should be placed in the part of the floor that will be least used and not
loaded with solid elements, thus protecting the sensor against possible mechanical damage.
The protective pipe of the temperature sensor should be routed in the floor, parallel to the
adjacent heating cables.
The end of the temperature sensor conduit must necessarily be within the planned location and
impact of the heating mat.
Insert the temperature sensor into the properly prepared conduit.
missionair
B I U R O @ M I S S I O N A I R . P L S E R W I S @ M I S S I O N A I R . P L W W W . M I S S I O N A I R . P LT E L . ( + 4 8 ) 7 9 7 4 5 1 1 1 1
M A L - 1 6 0 H E A T I N G M A T A S S E M B L Y M A N U A L
E N
