Mount the electrical box in the wall in the place where the temperature controller is to be installed,
remember to lead the mains power cables to the box,
Make a groove in the wall and in the floor for the protective conduit,*
Clean the floor thoroughly and then install the protective conduit with the floor temperature sensor.
Remember that the temperature sensor must be located directly under the influence of the heating mat,
run in parallel between the heating cables or between two strips of the mat, the sensor cable must not
intersect with the heating cable,*
Make the first measurement of the resistance of the heating wire and insulation. The measurement of the
resistance of the heating cable should be similar to the parameters shown in the table on the next page.
The measurement result should be entered in the warranty card. The insulation resistance should be
around 10Ω.
Spread the heating mat on the floor of the room in accordance with the previously prepared design.
Remember that the heating cable must not be cut. However, it is advisable to cut the mounting grid in
order to adjust the arrangement of the heating mat to the design and shape of the room. By properly
cutting the mesh, we can change the direction of the mat, avoid obstacles in the room, and even
reverse the direction of the mat, which will allow for the perfect arrangement of parallel stripes. The
possibilities of cutting the mesh, depending on the given situation, are presented on page 26.
It is recommended to take photographs of the heating mats laid out on the floor.
Insert the power cords into the protective pipe, and then into the flush-mounted box, where the
temperature controller will be installed.
At this stage, a second measurement of the system resistance should be made. The result should be
entered in the warranty card. If the second measurement differs significantly from the first and from the
data in the table, it means that the system was damaged during its installation in the room.
We proceed to the application of a flexible adhesive mortar intended for underfloor heating. The entire
mortar should be spread evenly over the entire surface, carefully surrounding the heating cables. The
thickness of the mortar should not exceed 5-6mm. Only a plastic trowel should be used for assembly
work. Be careful not to damage the heating cables, it is forbidden to use metal floats. Properly made
mortar should be left for 24 hours to dry.
After 24 hours, a control measurement of the system resistance should be made. If the measurement
differs significantly from the previous ones and from the data in the table, it means that the system was
damaged during the application of the adhesive mortar.
We can proceed to the installation of the floor covering using a flexible adhesive intended for
underfloor heating. The adhesive mortar should not be thicker than 5-6mm. Remember to perform all
preparatory activities related to cutting or shortening the tiles outside the underfloor heating installation
area.
After laying the floor covering and drying the glue, make the last measurement of the resistance of the
system. Record the result in the warranty card. If the measurement differs significantly from the previous
measurements and from the data in the table, it means that the system was damaged during the laying
of the tile covering.
In the previously prepared box with the mat power cables, mains power cables and optionally with the
temperature sensor cable, install the temperature regulator. During installation, follow the installation
instructions provided by the thermostat manufacturer.*
MA-160 HEATING MAT INSTALLATION:
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
Attention! The system should be connected by a qualified electrician.
*The wired floor temperature sensor is not configured with every temperature controller.
B I U R O @ M I S S I O N A I R . P L S E R W I S @ M I S S I O N A I R . P L W W W . M I S S I O N A I R . P LT E L . ( + 4 8 ) 7 9 7 4 5 1 1 1 1
M A - 1 6 0 H E A T I N G M A T A S S E M B L Y M A N U A L
