Page 35
Parts Manual - X17 ECO EXTRACTOR
230V Electrical Schematic Reference Numbers
Reference # Description Part Number
S1 SWITCH, BRUSH MOTOR 748602
S2 SWITCH, VACUUM MOTOR 748602
S3 SWITCH, SPRAY & AUXILARY 748603
S4 SWITCH, MICRO MOMENTARY PUMP 748611-1
CB1 CIRCUIT BREAKER, 1.0A BRUSH MOTOR 748696
CB2 CIRCUIT BREAKER, 7A VACUUM MOTOR 748672
CB3 CIRCUIT BREAKER, 1.0A PUMP/SOLENOID & AUXILIARY 748696
M1 MOTOR, BRUSH 832611-2
M2 MOTOR, VACUUM 740260-1
M3 PUMP. WATER 50 PSI 742150-1
M3 OPTIONAL: PUMP. WATER 100 PSI 742150-2
Y1 SOLENOID, WATER 740240-1
PG1 GAUGE, BRUSH PRESSURE 230VAC 748671
BR1 RECTIFIER, BRUSH MOTOR 740202
AUX RECEPTACLE, AUXILARY POWER 741038
RFI1 RFI FILTER, WATER PUMP 742256
RFI2 RFI FILTER, VACUUM MOTOR 742256
RFI3 RFI FILTER, BRUSH MOTOR 742256
C1 CAPACITOR ASM, 1uF WATER PUMP 748670-1
C2 CAPACITOR ASM, 330pF BRUSH MOTOR 742291-1
N1 FERRITE, LINE 742254
N2 FERRITE, WATER PUMP 742290
N3 FERRITE, BRUSH MOTOR 742290
X1 TERMINAL BLOCK, HANDLE ASSEMBLY 748616
X2 CONNECTOR, 9 PIN BULKHEAD (FEMALE) 748604
part of X2 CONNECTOR, 9 PIN PLUG (MALE) 748605
part of X2 SEAL, WIRES 9 PIN 748608
part of X2 SEAL, INTERFACE 9 PIN 748609
X3 TERMINAL BLOCK, BASE ASSEMBLY 748615
X4 CONNECTOR, 3 PIN CAP (FEMALE) 748631
part of X4 CONNECTOR, 3 PIN PLUG (MALE) 748632
part of X4 SEAL, WIRES 3P 748633
part of X4 SEAL, INTERFACE 3 PIN 748634
X5 CONNECTOR, 2 PIN CAP (FEMALE) 748624
part of X5 CONNECTOR, 2 PIN PLUG (MALE) 748625
part of X5 SEAL, WIRES 2 PIN 748626
part of X5 SEAL, INTERFACE 2 PIN 748627
