Page 23
Parts Manual - X17 ECO EXTRACTOR
Chassis Sub-Assembly BOM (Pg 1 of 2)
BILL OF MATERIAL - 173050 / 173050-HP / 173050-230 / 173050-230HP
ITEM PART # QTY DESCRIPTION
1 82-54-A 1 CLAMP, MS21333-114
2 7545-10 1 FLANGED BEARING ASSY
3 173004 1 MAINFRAME WELDMENT
4 173018 6 SPACER, FRONT PLATE
5
173033
1
EX17 - SPRAY BAR ASSEMBLY
173033HP EX17 - SPRAY BAR ASSEMBLY (HP MODELS ONLY)
6
173052
1
EX17 ECO SINGLE BRUSH ASSEMBLY (115V MODELS)
173052-230 EX17 ECO SINGLE BRUSH ASSEMBLY (230V MODELS)
7 173061 1 GUARD, BRUSH MOTOR
8 173064 2 SCR-ST PAN HD #6 x 3/8" SS
9 173070 1 GASKET, VACUUM SHOE
10
173076
1
PUMP ASY, 115V 50PSI EX17-ECO (115V MODEL)
173076-230 PUMP ASY, 230V 50PSI EX17-ECO (230V MODEL)
173076HP PUMP ASY, 115V 100PSI EX17-ECO (115V HP MODEL)
173076-230HP PUMP ASY, 230V 100PSI EX17-ECO (230V HP MODEL)
11 173078 2 WSR FLT 1/2 x 3/4 x .09 SS
12 173086 1 VACUUM SHOE, EX17 ECO
13 173096 1 CARRIAGE SCREWS 5/16-18 X 1-1/4 SS
14 173097 1 CARRIAGE SCREWS 5/16-18 X 1-3/4 SS
15 173108 1 BUSH, SIDE ARM
16 173109 1 BUSH, SIDE BRACKET
17 173113 1 WATER VALVE BRACKET
18 173120 1 FRONT SQUEEGEE PLATE
19 173146 1 FRONT PLATE NEOPRENE GASKET X17
20 173147 1 HOSE, 3/8 I.D x 7 IN
21 173148 1 HOSE, SPRAY BAR, 3/8 ID x 5.5 IN
22 173149 1 HOSE, PUMP 3/8 I.D x 4.5 IN
23 173150 1 HOSE, COUPLER 3/8 I.D x 12 IN
24 173151 1 HOSE, 3/8 ID x 17 IN
