Page 15
Ambassador Jr.
BOTTOM MAIN ASSEMBLY BOM (PG 1 OF 2)
BILL OF MATERIAL
ITEM PART NO. QTY DESCRIPTION
1 250038 1 RETAINER, BAG CLIP
2
380001
1
VAC MOTOR 6336-00 120V (115V MODEL)
740244 MOTOR-VAC 240V (230V MODEL)
3 380028 2 CARBON BRUSH REPLACEMENT
4
381020
1
CORD 16GA-3 50FT MED GREY (115V MODEL)
740600 CORD, EUROPEAN 1.5MM 50FT GREY (230V MODEL)
5 450019 1 ADJ. ROD BRUSH
6 450022 1 BELT-BRUSH 399-3M-06K
7 450026 1 BELT GUARD SC17 PTD
8 450030 1 WHEEL WELL PLATE RH
9 450031 1 WHEEL WELL PLATE LH
10 450034 2 PIN CLEVIS 5/16 X .75
11 450040 1 ELBOW PLT 3/8 MPT X 3/8 BARB
12 450052 1 BRUSH SHAFT AMB. JR
13 450055 2 HOSE NYLO 3/8 ID X 9”
14 450056 1 HOSE NYLOBRAID C/L 21”
15 450057 1 HOSE 3/8 ID X 20.5
16 450064 1 LOWER REAR PANEL
17 450068 1 BEARING, FLANGE MOUNTED
18 450074PLT 1 MOTOR SHROUD ZINC PLATED
19 450104 1 VACUUM AIR MANIFOLD
20 450106 1 MAINFRAME WELDMENT
21 450110 1 FRONT SQUEEGEE PLATE
22 450111 1 AXLE REAR AMB JR
23 450113 1 BRUSH BRACKET WELDMENT
24 450116 1 SPRAY TUBE ASSY AMB JR
25 450117 1 SPRAY TUBE PVC
26 450118 1 FRONT PLATE NEOPRENE GASKET
27 450119 1 MALE BRANCH T 1/4 BRASS
28 450121 1 BRUSH CORE AMB. JR ASR
29 450122 3 UNIJET SPRAY TIP 6503
30 452010 1 CABLE FLEXIBLE ASSEMBLY
31 452029 1 KNOB 1520 X BLK 1/4 BRAS
32 452037 4 CLAMP CRIMP 170R SS
33 700287 1 GROMMET
34 710130 2 SCR-MC 8-32 X .62 NICKEL
35 710207 3 SCR-MC 6-32 X .87 ST PL
36 710528 8 SCR-MC 8-32 X .37 BR
37 711124 11 SCR-ST-B 10 X .37 ZINC
38 711202 2 BLT-HH 1/4-20 X .50 ST PL
39 711301 3 NUT-HEX 6-32 ST PL
40 711420 3 NUT-HEX JAM 5/16-18 ST PL
