48

Model 1-6x24 (S) 1.6-10x42 (S) 2.2-14x50 (S) 3-18x56 (S) BDC

Magnification 1 - 6 x 1.6 - 10 x 2.2 - 14 x 3 - 18 x

Lens diameter (mm) 24 42 50 56

Diameter of exit pupil (mm) 10.0 - 4.0 9.9 - 4.2 9.8 - 3.6 9.8 - 3.1

Visual field in m at 100 m 40.0 - 6.7 24.4 - 4.0 17.6 - 2.9 13.3 - 2.2

Distance to exit pupil (mm) 90 90 90 90

Dioptre adjustment (dpt.) -3 / +2 -3 / +2 -3 / +2 -3 / +2

Elevation and lateral adjustment (per click) 1 cm / 100 m 1 cm / 100 m 1 cm / 100 m 1 cm / 100 m

Reticle adjustment range (Height x Side) 300 x 300 cm / 100 m 280 x 280 cm / 100 m 270 x 130 cm / 100 m 210 x 100 cm / 100 m

Parallax adjustment 100 m fix 100 m fix 50 m to∞ 50 m to∞

Illuminated reticle Yes, fibre optics Yes, fibre optics Yes, fibre optics Yes, fibre optics

Focus plane 2 2 2 2

Power supply for the illuminated reticle CR 2032 CR 2032 CR 2032 CR 2032

Nitrogen filling Yes Yes Yes Yes

Anti-fog and watertight Yes, 4 m for 30 min Yes, 4 m for 30 min Yes, 4 m for 30 min Yes, 4 m for 30 min

Weight (g) 560 (595) 635 (670) 725 (760) 800 (835)

Filter thread M28 x 0.75 M46 x 0.75 M54 x 0.75 M60 x 0.75

Order no. 80118303 I 80118304 (S) ( #4) 80118747 | 80118748 (S) 80118749 I 80118751 (S) 80118500 I 80118501 (S)

80118305 | 80118306 (S) (#54)

TECHNICAL DATA
