13
ENGLISH
DISPLAY (Figure 1.2)
A) Signal level
B) Volume
C) Zoom
D) Vox Mode
4.2. CAMERA FUNCTIONS AND CONTROLS (Figure 2)
I. Retractable antenna
II. Photo sensor
III. Power button
IV. Hanging attachment
V. Speaker XI. Infrared
VI. Link button
5. INSTRUCTIONS FOR USE
5.1. BEFORE USE
5.1.1. BABY UNIT POWER SUPPLY
The camera or baby unit of this baby monitor is designed for use with the AC/DC adapter
supplied.
1. Place the connector socket (VII) at the rear of the baby unit.
2. Connect the adapter cable to the mini-USB socket of the camera. Only use the adapter
supplied.
3. Plug in the adapter to the mains.
Warning: Danger of Strangulation – Keep the cable out of reach of the baby. NEVER place
a camera with cables less than 1 meter away from the cot. Never use extension cables
with AC adapters. Only use the AC adapters supplied
5.2. OPERATION
5.2.1. TURNING THE CAMERA ON/OFF
To turn the camera on or off, keep the on button (III) pressed in for two seconds. The ON/link LED
(IX) will go on and off depending on whether you turn the unit on or off.
When you have installed the camera and turned it on, you can see the images and listen to the
sounds captured in your baby’s room via the monitor.
Remember that to see the image of this camera on your monitor you must rst pair the units
following the instructions shown in section 5.2.6.
5.2.2. INFRARED NIGHT VISION (AUTOMATIC)
The infrared night vision function allows the camera to pick up images of your baby or the
monitored area in dark or low light conditions.
In this mode, only black and white images will be displayed on the monitor and only objects
located less than 2 meters away can be seen.
The camera constantly monitors the light level and automatically changes to infrared mode when
there is insufcient light for normal vision.
Note: The light sensor (II) is located at the top of the camera. Take care not to cover the sensor
with any object to prevent the camera from entering night mode when there is light in the room.
5.2.3. TRANSMISSION LEVEL
On this menu you can change the power level transmitted by the camera, choosing from amongst
the high/low options. When at the high position (HI), coverage will extend 250 meters in open
country with the original power. When at the low position (LOW), the maximum transmission
distance is reduced to around 120 meters in open country as the transmitting power is reduced.
To congure the transmission level, follow the next steps:
1. Press the Menu/Back key and the menu will pop up.
2. Press the UP key or DOWN key until the transmission level menu icon is highlighted
then press the key.
E) Transmission level
F) Selected camera
G) Battery level
H) Talk to the baby activated indicator
VII. Mini USB power connector
VIII. Microphone
IX. ON/link LED
X. Camera lens
XII. Tripod attachment
