MJC680-2 Rev AA April 2019

Ref. no Description Part No. Qty

1 Sheave Housing JM33-1 1

2 Transmission Housing JM35-1 1

3 Transmission Cover JM34-2 1

4 Electrical Cover JM36 1

5 Chain Support Pin (2 ton only) JM111 1

6 Chain Support (2 ton only) JM109 1

7 Chain Stripper JM254 1

8 Chain Stop Kit (Kits include halves, sleeve and retaining ring) 75JG6K 1

9 Load Chain JL19-1 *

10 Attachment Pin JM18-3 1

11 Retaining Clip H5597 1

12 1/4-20UNC x 1¼" Socket Head Cap Screw S49-77 1

13 Bottom Block Assembly 1 ton & Under 913JG3AS 1

14 1/4-20UNC x 1¼" Socket Head Cap Screw S49-77 2

15 1/4" Internal-tooth Lockwasher H4134 2

16 Load Block Frame 30J14 2

17 Load Block Pin 18J8 1

18 Slotted Hex Nut H3986P 1

19 Bearing JF510 1

20 Latch Kit 4X1304 1

21 Bottom Hook Assembly with Latch for 1 Ton & Under 3JG20S 1

22 Bottom Block Assembly for 2 Ton JF914-6 1

23 3/8-24 Hex Locknut H3964P 2

24 Load Block Screw H2403P 2

25 Load Block Frame JF30-1 2

26 Sheave Shaft Assembly JF917-1 1

27 Sheave Shaft JF122-1 1

28 Idler Sheave & Bearing Assembly JF916 1

29 Roll Pin H5234 2

30 3/8-24 Hex Locknut H3991P 1

31 Bearing JF511 1

32 Latch Kit 4X1305 1

33 Bottom Hook Assembly with Latch for 2 Ton 3KG1W 1

FIGURE 24 — CHAINING PARTS CONTINUED

Parts List for Chaining Parts

* Replacement chain is sold by the foot. For single-chained models, add 2 ft to the lift for the total amount of feet. For double-chained models, double the lift and add 3 ft.
