30
MJC680-2 Rev AA April 2019
Part No. Ref No. Description Qty.
18 Screw M3 x 1.34 x 35mm Lg Thd Roll Plstc 4
24 Pendant Switch 4
25 Rocker Plate 1
27 Washer M3 x 6mm OD Sst 2
- Instruction Sheet 1
ECUR-0011 Switch Repair Kit, 1 Speed, 2 Switch 1
7 Switch Gasket 1
10 Switch Housing 1
12 Pin Hinge 1
14 Retainer Plate 1
17 Screw M3 X 1.34 X 16Mm Lg Thd Roll Plstc 2
18 Screw M3 X 1.34 X 35Mm Lg Thd Roll Plstc 4
24 Pendant Switch 2
25 Rocker Plate 1
27 Washer M3 X 6mm Od Sst 2
- Instruction Sheet 1
ECUR-0020 Enclosure Repair Kit, No E-Stop 1
3 Strain Relief Collar 1
4 Pendant Enclosure Back 1
5 Pendant Enclosure Front 1
6 Pendant Enclosure Top, No E-Stop 1
N/S Cord Gasket 1
Enclosure Hardware Kit 1
13 Strain Relief Plate 1
16 Screw M3 x 1.34 x 12mm Lg Thd Roll Plstc 4
19 Screw M4 x 1.79 x 12mm Lg Thd Roll Plstc 1
18 Screw M4 x 1.79 X 33.5mm Lg Thd Roll Plstc 2
23 Strain Relief 1
27 Washer M3 x 6mm Od Sst 4
29 Washer M4 Lk Sst 2
28 Washer M4 x 8mm Od Sst 3
- Instruction Sheet 1
ECUR-0021 Enclosure Repair Kit, With E-Stop 1
3 Coller Strain Relief Ergo Pendant 1
4 Enclosure Pendant Ergo Back 1
5 Enclosure Pendnat Ergo Front 1
6 Enclosure Pendnat Ergo Top 1
Gasket Silicone Cord Ergo Pendant 1
Hardware Kit Enclosure Ergo Pndnt 1
13 Plate Strain Relief Ergo 1
16 Screw M3 x 1.34 x 12mm Lg Thd Roll Plstc 4
19 Screw M4 x 1.79 x 12mm Lg Thd Roll Plstc 1
18 Screw M4 x 1.79 x 33.5mm Lg Thd Roll Plstc 2
23 Strain Relief 1
27 Washer M3 x 6Mm Od Sst 4
29 Washer M4 Lk Sst 2
28 Washer M4 x 8mm Od Sst 3
- Instruction Sheet 1
ECUR-0030 Pendant Label Kit 1
N/S Instruction Sheet 1
N/S Logo Sticker Sheet 1
62809 N/S Cord Warning Tag 1
23608124 24 Emergency Stop Push Button 1
23608110 2 Cable Bushing 1
