Milwaukee 9570 handleiding
Handleiding
Je bekijkt pagina 28 van 32
Milwaukee Electric Tool Corporation
13135 West Lisbon Road
Brookfield, Wisconsin 53005
TEL: (800) 729-3878
27
1 Sheave Housing
1/2 Ton 1
1 & 2 Ton 1
2 Gear Housing
1/2 Ton 1
1 & 2 Ton 1
3 Dowel Pin 2
4 Load Sheave
1/2 Ton 1
1 & 2 Ton 1
5 Load Sheave Shaft 1
6 Roll Pin 1
7 Spacer, 1 & 2 Ton 1
8 Chain Guide
1/2 Ton 2
1 & 2 Ton 2
9 Chain Guide Screw 2
10 Washer, 1/2 Ton 2
11 Chain Guide Plate
1/2 Ton 2
1 & 2 Ton 2
12 Chain Guide Plate Screw 2
13 Chain Guide Plate Spacer 2
14 Bearing 2
15 Dead End Screw 1
16 1/4" Flatwasher 8
17 Dead End Nut 1
18 Load Chain
1/2 Ton •
1 & 2 Ton •
19 Chain Stop Kit
1/2 Ton 1
1 & 2 Ton 1
(Kits include halves,
sleeve, and retaining ring)
20 Chain Support 1
21 Chain Support Pin 1
22 Cotter Pin 1
23 Lockwasher 1
24 1/2-20UNF Hex Jam Nut 1
25 Chain Support Screw 1
26 Load Block Assembly, 1/2 Ton 1
27 Load Block Frame 1
28 Load Block Frame (Threaded) 1
29 Load Block Screw 1
30 Load Block Assembly, 1 Ton 1
31 Load Block Frame 2
32 1/4-20UNC x 1¼"
Socket Head Cap Screw 2
33 1/4" Internal-Tooth Lockwasher 2
34 Load Block Pin 1
35 Bottom Hook Assembly
w/Latch, 1 & 1/2 Ton 1
36 Latch Kit 1
37 Slotted Hex Nut 1
38 Bearing 1
39 Load Block Assembly, 2 Ton 1
40 Load Block Frame 2
41 Load Block Screw 2
42 3/8-24 UNF Hex Locknut 2
43 Sheave Shaft Assembly 1
44 Sheave & Bearing Assembly 1
45 Sheave Shaft 1
46 Roll Pin 2
47 Bottom Hook Assembly
with Latch, 2 Ton 1
48 Latch Kit 1
49 Slotted Hex Nut 1
50 Bearing 1
Parts List for Chaining Parts
Ref Description Qty Ref Description Qty
No. No.
